Specifications
| Feature | Specification |
| Unique Features | Super Alloy, XXL Aluminum Heatsink, 50A Power Choke, Sapphire Black PCB, Hyper M.2 (PCIe Gen4x4), POST Status Checker, Full Spike Protection |
| CPU Support | AMD AM4 Ryzen 3000, 4000, 5000 series, 8 Power Phase Digi Power design |
| Chipset | AMD PRO565 |
| Memory | Dual-channel DDR4, 4 DIMM slots, up to 128GB, up to DDR4 4733+(OC) for APUs, 4533+(OC) for CPUs, ECC/non-ECC support |
| Graphics | Integrated AMD Radeon Vega Graphics, DirectX 12, HDMI 2.1 (4K @ 60Hz), 16GB max shared memory |
| Audio | 7.1 CH HD Audio, Realtek ALC1220 Codec, Blu-ray support, Surge Protection |
| LAN | Gigabit LAN (Realtek RTL8111H), Wake-On-LAN, Lightning/ESD Protection |
| Wireless | Intel 802.11ac WiFi, Dual-band 2.4/5 GHz, Bluetooth 4.2, speed up to 433 Mbps |
| Expansion Slots | 2 x PCIe x16 (Gen4/Gen3), 1 x PCIe x1, AMD Quad CrossFireX |
| Storage | 4 x SATA3 6Gb/s, 1 x Hyper M.2 (Gen4x4/Gen3x4) |
| I/O Ports (Rear) | 2 x Antenna Ports, 1 x PS/2 Mouse/Keyboard, 1 x HDMI, 4 x USB 3.2 Gen1, 2 x USB 2.0, 1 x RJ-45 LAN, Audio Jacks |
| Cooling | 1 x CPU Fan Connector, 3 x Chassis/Water Pump Fan Connectors, Smart Fan Control |
| Connectors | 1 x COM, 1 x SPI TPM, 2 x RGB LED, 2 x Addressable LED, 2 x USB 3.2 Gen1 Headers, 2 x USB 2.0 Headers, 24-pin ATX, 8-pin 12V |
| Form Factor | Micro ATX, 9.6″ x 9.6″, 2oz Copper PCB |
| Software | ASRock Utility (A-Tuning), Polychrome SYNC |
| BIOS | 256Mb UEFI, Plug and Play, ACPI 5.1, Jumperfree, Multi-Voltage Adjustment |
| OS Support | Windows 10/11 64-bit |
| Accessories | I/O Shield, 2 x SATA cables, 2 x WiFi Antennas, M.2 Screw |
Key Features
- 8 Power Phase Digi Power Design for stable power delivery to AMD AM4 Ryzen 3000/4000/5000 series CPUs.
- Dual‑Channel DDR4 Support – 4 DIMM slots, up to 128 GB, speeds up to DDR4 4733+(OC) for APUs and DDR4 4533+(OC) for CPUs.
- Integrated Wi‑Fi & Bluetooth – Intel 802.11ac dual‑band (2.4/5 GHz) Wi‑Fi up to 433 Mbps + Bluetooth 4.2.
- Hyper M.2 Slot (PCIe Gen4x4) – Ultra‑fast NVMe storage plus 4 × SATA3 6 Gb/s ports.
- Premium Audio – 7.1‑channel HD Audio with Realtek ALC1220 codec, Blu‑ray support and surge protection.
- Robust Build – Super Alloy design, XXL aluminum heatsink, 50A power choke, sapphire‑black PCB, full spike protection.
- Comprehensive Cooling & Fan Control – 1 CPU fan header, 3 chassis/water‑pump fan headers, Smart Fan Control.
- Micro‑ATX Form Factor – 9.6″ × 9.6″ board fits compact cases while offering full feature set.
