Specifications
| Bearing Type | Hydro Bearing |
| Fan Air Pressure | 2.53 mmAq |
| Fan Airflow | 75.89 CFM |
| Fan Connector | 4-pin PWM |
| Fan Dimensions | 120×120×25 mm(L×W×H) |
| Fan Noise | ≤31.6 dB(A) |
| Fan Power Consumption | 2.04 W |
| Fan Rated Current | 0.17 A |
| Fan Rated Voltage | 12 VDC |
| Fan Speed | 500~2100 RPM±10% |
| LED Connector | 3-pin(+5V-D-G) |
| LED Power Consumption | 2.8 W（PUMP）/ 2.1 W（FAN×2） |
| LED Rated Voltage | 5 VDC |
| LED Type | Addressable RGB LED |
| Net Weight | 1359 g |
| P/N | R-LE240-BKAMMC-G-2 |
| Pump Connector | 4-pin PWM |
| Pump Dimensions | 91×78×65 mm(L×W×H) |
| Pump Power Consumption | 3.48 W |
| Pump Rated Current | 0.29 A |
| Pump Rated Voltage | 12 VDC |
| Pump Speed | 2500~3400 RPM±10% |
| Radiator Dimensions | 282×120×27 mm(L×W×H) |
| Radiator Material | Aluminum |
| Tube length | 410 mm(L×W×H) |
Key Features
- Hydro Bearing pump design for low friction and extended lifespan.
- Dual 120 mm PWM fans delivering 75.89 CFM airflow and 2.53 mmAq static pressure, speed 500‑2100 RPM, noise ≤31.6 dB(A).
- Addressable RGB lighting with 3‑pin (+5V‑D‑G) connector for customizable ARGB effects.
- High‑speed pump operating at 2500‑3400 RPM, powered at 3.48 W (12 V, 0.29 A) for rapid heat transfer.
- 240 mm aluminum radiator measuring 282 × 120 × 27 mm with 410 mm tubing for efficient cooling.
- 4‑pin PWM connectors for both fan and pump, enabling precise voltage‑frequency control.
- Lightweight construction at only 1359 g, easy to install in most cases.
