Specifications
| Model | PRIME-RTX5060-O8G |
| Graphics Engine | NVIDIA® GeForce RTX™ 5060 |
| AI Performance | 630 TOPs |
| Bus Standard | PCI Express 5.0 |
| OpenGL Support | OpenGL® 4.6 |
| Video Memory | 8GB GDDR7 |
| Engine Clock | OC Mode: 2595 MHz ; Default Mode (Boost Clock): 2565 MHz |
| CUDA Cores | 3840 |
| Memory Speed | 28 Gbps |
| Memory Interface | 128-bit |
| Max Digital Resolution | 7680 x 4320 |
| Display Outputs | 1x HDMI 2.1b (Native) ; 3x DisplayPort 2.1b (Native) |
| HDCP Support | Yes (2.3) |
| Maximum Displays | 4 |
| NVLink / CrossFire | No |
| Accessories | 1x Speed setup Manual ; 1x Thank You Card |
| Software | ASUS GPU Tweak III, MuseTree, GeForce Game Ready Driver, Studio Driver (download from support site) |
| Dimensions (L x W x H) | 268.3 x 120 x 50 mm(10.56 x 4.72 x 1.97 inches) |
| Recommended PSU | 550W |
| Power Connectors | 1x 8-pin |
| Slot Size | 2.5 Slot |
| SFF Ready | Compatible |
| Notes | Wattage recommendation based on OC system. Specs subject to change without notice. |
| Warranty | 3 Years |
Key Features
- GPU: NVIDIA GeForce RTX 5060 with 3840 CUDA cores
- Memory: 8GB GDDR7, 28 Gbps speed, 128-bit interface
- Clock Speeds: OC Mode up to 2595 MHz, Default Boost 2565 MHz
- Interface & Resolution: PCI Express 5.0, max digital resolution 7680×4320
- Display Outputs: 1× HDMI 2.1b + 3× DisplayPort 2.1b (supports up to 4 monitors)
- Power & Cooling: 1× 8‑pin power connector, recommended 550W PSU, 2.5‑slot design
- Software & Warranty: ASUS GPU Tweak III included, 3‑year warranty
