Specifications
| Model Name | PRIME-RX9060XT-O16G |
| Graphics Engine | AMD Radeon™ RX 9060 XT |
| Bus Standard | PCI Express 5.0 |
| OpenGL Version | OpenGL® 4.6 |
| Video Memory | 16GB GDDR6 |
| Memory Speed | 20 Gbps |
| Memory Interface | 128-bit |
| Stream Processors | 2048 |
| Engine Clock (OC Mode) | Boost: Up to 3330 MHzGame: Up to 2760 MHz |
| Engine Clock (Default) | Boost: Up to 3310 MHzGame: Up to 2740 MHz |
| Digital Max Resolution | 7680 x 4320 |
| Display Outputs | 1x HDMI 2.1b2x DisplayPort 2.1a |
| HDCP Support | Yes (2.3) |
| Maximum Display Support | 3 Displays |
| NVLink / CrossFire Support | No |
| Recommended PSU | 550W |
| Power Connectors | 1x 8-pin |
| Slot Size | 2.5-slot |
| Card Dimensions (mm) | 304 × 126 × 50 mm |
| Accessories | 1x Thank You Card ; 1x Speed Setup Manual |
| Software | ASUS GPU Tweak III & Drivers (Download from support site) |
| Warranty | 3 Years |
Key Features
- GPU: AMD Radeon™ RX 9060 XT with 2048 Stream Processors
- Memory: 16 GB GDDR6, 20 Gbps speed, 128‑bit interface
- Clock Speeds (OC Mode): Boost up to 3330 MHz, Game up to 2760 MHz (Default: Boost up to 3310 MHz, Game up to 2740 MHz)
- Display & Resolution: 1× HDMI 2.1b + 2× DisplayPort 2.1a, max 7680 × 4320 (8K), support for up to 3 displays
- Interface & Form Factor: PCI Express 5.0 x16, 2.5‑slot, 304 × 126 × 50 mm
- Power: Single 8‑pin connector, recommended 550 W PSU
- Software & Warranty: ASUS GPU Tweak III, 3‑year warranty
