Specifications
| Powered by | the NVIDIA Blackwell Architecture and DLSS 4 |
| Dedicated Tensor | Cores |
| Dedicated RT | Cores |
| Microsoft DirectX® | 12 Ultimate |
| GDDR7 Graphics | Memory |
| NVIDIA DLSS | 4 |
| NVIDIA G | SYNC® |
| NVIDIA GPU | Boost™ |
| Game Ready | and NVIDIA Studio Drivers |
| DisplayPort 2.1b, | HDMI 2.1b |
| To 1 | Click OC, overclock, control ARGB and monitor GPU info of your graphics cards in-App, please make sure your mobile device and PC are connected with the same WiFi network. |
| All photos, | specifications, contents are used for reference only and are subject to change without notice. Actual products in different countries varies and are best to consult your local distributor / importer for confirmation. |
| CUDA Cores | 8960 |
| Boost Clock | 2467 MHz |
| 1-Click OC Clock | 2482 (by installing Xtreme Tuner Plus Software and using 1-Click OC) |
| Memory Speed | 28 Gbps |
| Standard Memory Config | 16GB GDDR7 |
| Memory Interface Width 256 | bit |
| Memory Bandwidth | 896 GB/sec |
| PCI | E 5.0 |
| Windows 10/11 64 | bit |
| WINGS 3.0 | with Fan stop @ Idle (All Fans) |
| DisplayPort 2.1b | x 3, HDMI 2.1b x 1 |
| Dimensions(with Bracket) | 315*140.5*50.7mm (NVIDIA SFF-Ready) |
| Dimensions(without Bracket) | 303*125*49.7mm |
| 1 | Click sync pro cable |
| PCIe 1x 16 | pin to 3x 8-pin adapter |
| Metallic support | stick |
Key Features
- Powerful GPU: NVIDIA Blackwell Architecture with 8,960 CUDA cores and a boost clock of 2,467 MHz (2,482 MHz with 1‑Click OC).
- High‑speed Memory: 16 GB GDDR7 memory running at 28 Gbps, 256‑bit interface delivering 896 GB/s bandwidth.
- Advanced Display Support: Triple DisplayPort 2.1b and HDMI 2.1b outputs for ultra‑high‑resolution, high‑refresh gaming.
- PCIe 5.0 Compatibility: Full PCIe 5.0 x16 interface for maximum data throughput.
- Intelligent Cooling: WINGS 3.0 fan‑stop technology shuts all fans at idle for silent operation.
- 1‑Click Overclock & Monitoring: Xtreme Tuner Plus software enables 1‑Click OC, ARGB control, and GPU monitoring via a mobile app.
- Compact SFF‑Ready Design: Dimensions 315 × 140.5 × 50.7 mm (with bracket) fit small form‑factor builds.
