Specifications
| Graphics Processing | GeForce RTX™ 5070 |
| Core Clock | 2625 MHz (Reference: 2512 MHz) |
| CUDA® Cores | 6144 |
| Memory Clock | 28 Gbps |
| Memory Size | 12 GB |
| Memory Type | GDDR7 |
| Memory Bus | 192-bit |
| Card Bus | PCI Express 5.0 |
| Max Digital Resolution | 7680 x 4320 |
| Multi-view Support | 4 Displays |
| Card Size (mm) | 324 (L) x 130 (W) x 56 (H) |
| PCB Form | ATX |
| DirectX | DirectX 12 API |
| OpenGL | 4.6 |
| Recommended PSU | 750W |
| Power Connectors | 1x 16-pin (12V-2×6) |
| Output Ports | 3x DisplayPort 2.1b1x HDMI 2.1b |
| Accessories | Quick Guide, Warranty Registration, 1x 12V-2×6 to 2x PCIe 8-pin Adapter, Versatile VGA Holder, VGA Holder Manual |
| Warranty | 3 Years |
Key Features
- Powerful GPU: NVIDIA GeForce RTX 5070 with 6,144 CUDA cores.
- High Boost Clock: 2,625 MHz boost (reference 2,512 MHz) for fast performance.
- 12 GB GDDR7 Memory: 28 Gbps memory speed on a 192‑bit bus.
- PCIe 5.0 Interface: Next‑generation card bus for maximum bandwidth.
- Multi‑Display Support: 3× DisplayPort 2.1 and 1× HDMI 2.1, up to 4 displays.
- 8K Resolution Capability: Max digital resolution of 7,680 × 4,320.
- Robust Power Delivery: 1× 16‑pin (12V‑2×6) connector, recommended 750 W PSU.
- Warranty: 3‑year limited warranty.
