Specifications
| Graphics Processing | NVIDIA® GeForce RTX™ 5060 Ti |
| Core Clock | 2572 MHz (Reference Clock) |
| CUDA® Cores | 4608 |
| Memory Clock | 28 Gbps |
| Memory Size | 8GB |
| Memory Type | GDDR7 |
| Memory Bus | 128-bit |
| Card Bus | PCI Express 5.0 |
| Digital Max Resolution | 7680 × 4320 (8K) |
| Multi-View Support | 4 Displays |
| Card Size (L × W × H) | 208 × 120 × 40 mm |
| PCB Form Factor | ATX |
| DirectX Support | DirectX 12 API |
| OpenGL Support | OpenGL 4.6 |
| Recommended PSU | 650W |
| Power Connectors | 1 × 8-pin |
| Display Outputs | 3 × DisplayPort 2.1b1 × HDMI 2.1b |
| Accessories Included | Quick Guide |
Key Features
- NVIDIA GeForce RTX 5060 Ti GPU delivering 4608 CUDA cores for high-performance gaming and content creation.
- Boost Clock up to 2572 MHz ensures fast frame rates in demanding titles.
- 8 GB GDDR7 memory running at 28 Gbps on a 128‑bit bus for ample bandwidth and smooth textures.
- PCI Express 5.0 interface provides future‑proof bandwidth and low latency.
- Supports up to 8K (7680 × 4320) resolution and 4 simultaneous displays via 3 × DisplayPort 2.1 and 1 × HDMI 2.1.
- Compact ATX form factor (208 × 120 × 40 mm) with GIGABYTE Windforce cooling for efficient thermal management.
- Recommended 650 W PSU with a single 8‑pin power connector for reliable power delivery.
