| Processor Number |
i3-12100 |
| Lithography |
Intel 7 |
| Total |
Cores 4 |
| Performance-cores |
4 |
| Total Threads |
8 |
| Max Turbo Frequency |
4.30 GHz |
| Performance-core Max Turbo Frequency |
4.30 GHz |
| Performance-core Base Frequency |
3.30 GHz |
| Cache |
12 MB Intel Smart Cache |
| Total L2 Cache |
5 MB |
| Processor Base Power |
60 W |
| Maximum Turbo Power |
89 W |
| Embedded Options Available |
Yes |
| Max Memory Size (dependent on memory type) |
128 GB |
| Memory Types |
Up to DDR5 4800 MT/s |
| Max # of Memory Channels |
2 |
| Max Memory Bandwidth |
76.8 GB/s |
| Processor Graphics |
Intel UHD Graphics 730 |
| Graphics Base Frequency |
300 MHz |
| Graphics Max Dynamic Frequency |
1.40 GHz |
| Graphics Output |
eDP 1.4b, DP 1.4a, HDMI 2.1 |
| Execution Units |
24 |
| Max Resolution (HDMI) |
4096 x 2160 @ 60Hz |
| Max Resolution (DP) |
7680 x 4320 @ 60Hz |
| Max Resolution (eDP – Integrated Flat Panel) |
5120 x 3200 @ 120Hz |
| DirectX* Support |
12 |
| OpenGL* Support |
4.5 |
| Multi-Format Codec Engines |
1 |
| Intel Quick Sync Video |
Yes |
| Intel Clear Video HD Technology |
Yes |
| # of Displays Supported á |
4 |
| Device ID |
0x4692 |
| OpenCL* Support |
2.1 |
| Direct Media Interface (DMI) Revision |
4.0 |
| Max # of DMI Lanes |
8 |
| Scalability |
1S Only |
| PCI Express Revision |
5.0 and 4.0 |
| PCI Express Configurations |
Up to 1×16+4, 2×8+4 |
| Max # of PCI Express Lanes |
20 |
| Sockets Supported |
FCLGA1700 |
| Max CPU Configuration |
1 |
| Thermal Solution Specification |
PCG 2020C |
| TJUNCTION |
100∞C |
| Package Size |
45.0 mm x 37.5 mm |
| Intel Gaussian & Neural Accelerator |
3.0 |
| Intel Thread Director |
No |
| Intel Deep Learning Boost (Intel DL Boost) |
Yes |
| Intel Optane Memory Supported |
Yes |
| Intel Speed Shift Technology |
Yes |
| Intel Turbo Boost Max Technology 3.0 |
No |
| Intel Turbo Boost Technology |
2.0 |
| Intel Hyper-Threading Technology |
Yes |
| Intel 64 |
Yes |
| Instruction Set |
64-bit |
| Instruction Set Extensions |
Intel SSE4.1, Intel SSE4.2, Intel AVX2 |
| Idle States |
Yes |
| Enhanced Intel Speed Step Technology |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Intel Volume Management Device (VMD) |
Yes |
| Intel Threat Detection Technology (TDT) |
Yes |
| Intel Standard Manageability (ISM) |
Yes |
| Intel AES New Instructions |
Yes |
| Secure Key |
Yes |
| Intel OS Guard |
Yes |
| Execute Disable Bit |
Yes |
| Intel Boot Guard |
Yes |
| Mode-based Execute Control (MBEC) |
Yes |
| Intel Control-Flow Enforcement Technology |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Warranty |
3 Years |
