| Product Collection |
13th Generation Intel Core i5 Processors |
| Code Name |
Products formerly Raptor Lake |
| Vertical Segment |
Desktop |
| Processor Number |
i5-13600KF |
| Lithography |
Intel 7 |
| Use Conditions |
PC/Client/Tablet |
| Total Cores |
14 |
| # of Performance-cores |
6 |
| # of Efficient-cores |
8 |
| Total Threads |
20 |
| Max Turbo Frequency |
5.10 GHz |
| Performance-core Max Turbo Frequency |
5.10 GHz |
| Efficient-core Max Turbo Frequency |
3.90 GHz |
| Performance-core Base Frequency |
3.50 GHz |
| Efficient-core Base Frequency |
2.60 GHz |
| Cache |
24 MB Intel Smart Cache |
| Total L2 Cache |
20 MB |
| Processor Base Power |
125 W |
| Maximum Turbo Power |
181 W |
| Embedded Options Available |
No |
| Datasheet |
View now |
| Max Memory Size (dependent on memory type) |
128 GB |
| Memory Types |
Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s |
| Max # of Memory Channels |
2 |
| Max Memory Bandwidth |
89.6 GB/s |
| Direct Media Interface (DMI) Revision |
4 |
| Max # of DMI Lanes |
8 |
| Scalability |
1S Only |
| PCI Express Revision |
5.0 and 4.0 |
| PCI Express Configurations á |
Up to 1×16+4 | 2×8+4 |
| Max # of PCI Express Lanes |
20 |
| Sockets Supported |
FCLGA1700 |
| Max CPU Configuration |
1 |
| TJUNCTION |
100∞C |
| Intel Gaussian & Neural Accelerator |
3 |
| Intel Thread Director |
Yes |
| Intel Deep Learning Boost (Intel DL Boost) |
Yes |
| Intel Speed Shift Technology |
Yes |
| Intel Turbo Boost Max Technology 3.0 |
No |
| Intel Turbo Boost Technology |
2 |
| Intel Hyper-Threading Technology |
Yes |
| Intel 64 |
Yes |
| Instruction Set |
64-bit |
| Instruction Set Extensions |
Intel SSE4.1 | Intel SSE4.2 | Intel AVX2 |
| Idle States |
Yes |
| Enhanced Intel Speed Step Technology |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Intel Volume Management Device (VMD) |
Yes |
| Intel Standard Manageability (ISM) |
Yes |
| Intel Control-Flow Enforcement Technology |
Yes |
| Intel AES New Instructions |
Yes |
| Secure Key |
Yes |
| Intel OS Guard |
Yes |
| Execute Disable Bit |
Yes |
| Intel Boot Guard |
Yes |
| Mode-based Execute Control (MBEC) |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Warranty |
3 Years |
