INTEL CORE ULTRA 7 265K 20 CORE UPTO 5.5 GHZ LGA1851 PROCESSOR


The Intel Core Ultra 7 265K processor features 20 cores (8 Performance-cores and 12 Efficient-cores) and 20 threads. It delivers a maximum turbo frequency of up to 5.5GHz, with Performance-cores reaching 5.4GHz and Efficient-cores reaching 4.6GHz. Base frequencies are 3.9GHz for Performance-cores and 3.3GHz for Efficient-cores.

Specifications

Total Cores 20
# of Performance-cores 8
# of Efficient-cores 12
Total Threads 20
Max Turbo Frequency 5.5GHz
Intel® Turbo Boost Max Technology 3.0 Frequency 5.5GHz
Performance-core Max Turbo Frequency 5.4GHz
Efficient-core Max Turbo Frequency 4.6GHz
Performance-core Base Frequency 3.9GHz
Efficient-core Base Frequency 3.3GHz
Cache 30 MB Intel® Smart Cache
Total L2 Cache 36 MB
Processor Base Power 125 W
Maximum Turbo Power 250 W
Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes
AI Software Frameworks Supported by CPU OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
CPU Lithography TSMC N3B
Max Memory Size (dependent on memory type) 192 Gb
Memory Types Up to DDR5 6400 MT/s
Maximum Memory Speed 6400 Mhz
Max # of Memory Channels 2
ECC Memory Supported Yes
GPU Name Intel Graphics
Graphics Base Frequency 300 Mhz
Graphics Max Dynamic Frequency 2 GHz
GPU Peak TOPS (Int8) 8
Graphics Output DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b
Xe-cores 4
Max Resolution (HDMI) 4K @ 60Hz (HDMI 2.1 TMDS) 8K @ 60Hz (HDMI2.1 FRL)
Max Resolution (DP) 8K @ 60Hz
Max Resolution (eDP – Integrated Flat Panel)‡ 4K @ 60Hz
DirectX* Support 12
OpenGL* Support 4.5
OpenCL* Support 3
Intel® Quick Sync Video Yes
# of Displays Supported 2
Intel® Deep Learning Boost (Intel® DL Boost) on GPU Yes
NPU Name Intel® AI Boost
NPU Peak TOPS (Int8) 13
Sparsity Support Yes
Windows Studio Effects Support Yes
AI Software Frameworks Supported by NPU OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
Direct Media Interface (DMI) Revision 4
Max # of DMI Lanes 8
Intel® Thunderbolt™ 4 Yes
Scalability 1S Only
PCI Express Revision 5.0 and 4.0
PCI Express Configurations Up to 1×16+2×4, 2×8+2×4, 1×8+4×4
Max # of PCI Express Lanes 24
Sockets Supported FCLGA1851
Thermal Solution Specification PCG 2020A
Max Operating Temperature 105 °C
Intel® Volume Management Device (VMD) Yes
Intel® Gaussian & Neural Accelerator 3.5
Intel® Thread Director Yes
Intel® Speed Shift Technology Yes
Intel® Turbo Boost Max Technology 3.0 Yes
Intel® Turbo Boost Technology 2
Intel® 64 Yes
Instruction Set 64 Bit
Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
Intel vPro® Eligibility Intel vPro® Enterprise, Intel vPro® Platform
Intel® Threat Detection Technology (TDT) Yes
Intel® Active Management Technology (AMT) Yes
Intel® Standard Manageability (ISM) Yes
Intel® Remote Platform Erase (RPE) Yes
Intel® One-Click Recovery Yes
Intel® Hardware Shield Eligibility Yes
Intel® Control-Flow Enforcement Technology Yes
Intel® Total Memory Encryption – Multi Key Yes
Intel® AES New Instructions Yes
Secure Key Yes
Intel® Trusted Execution Technology Yes
Execute Disable Bit Yes
Intel® OS Guard Yes
Intel® Boot Guard Yes
Mode-based Execute Control (MBEC) Yes
Intel® Stable IT Platform Program (SIPP) Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp) Yes
Intel® Virtualization Technology (VT-x) Yes
Intel® Virtualization Technology for Directed I/O (VT-d) Yes
Intel® VT-x with Extended Page Tables (EPT) Yes
Warranty 3 Years
Note** **Prices, Specifications & Features are subject to change without notice

Key Features

  • 20 Cores / 20 Threads — 8 Performance-cores + 12 Efficient-cores
  • Up to 5.5 GHz Turbo Frequency — Intel® Turbo Boost Max 3.0 Technology
  • 30 MB Smart Cache + 36 MB L2 Cache
  • 192 GB DDR5-6400 Memory Support — 2 channels, ECC supported
  • Intel® AI Boost NPU — 13 TOPS (Int8) for AI acceleration
  • Intel® Graphics — 4 Xe-cores, up to 2 GHz, supports 8K@60Hz
  • PCIe 5.0 & Thunderbolt™ 4 — 24 lanes, up to 1×16+2×4 configuration
  • 3-Year Warranty
