| Total Cores |
24 |
| # of Performance-cores |
8 |
| # of Efficient-cores |
16 |
| Total Threads |
24 |
| Max Turbo Frequency |
5.7GHz |
| Intel® Thermal Velocity Boost Frequency |
5.7 GHz |
| Intel® Turbo Boost Max Technology 3.0 Frequency |
5.6 GHz |
| Performance-core Max Turbo Frequency |
5.5GHz |
| Efficient-core Max Turbo Frequency |
4.6GHz |
| Performance-core Base Frequency |
3.7GHz |
| Efficient-core Base Frequency |
3.2GHz |
| Cache |
36 MB Intel® Smart Cache |
| Total L2 Cache |
40 MB |
| Processor Base Power |
125 W |
| Maximum Turbo Power |
250 W |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU |
Yes |
| AI Software Frameworks Supported by CPU |
OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN |
| CPU Lithography |
TSMC N3B |
| Max Memory Size (dependent on memory type) |
192 Gb |
| Memory Types |
Up to DDR5 6400 MT/s |
| Maximum Memory Speed |
6400 Mhz |
| Max # of Memory Channels |
2 |
| ECC Memory Supported |
Yes |
| GPU Name |
Intel Graphics |
| Graphics Base Frequency |
300 Mhz |
| Graphics Max Dynamic Frequency |
2 GHz |
| GPU Peak TOPS (Int8) |
8 |
| Graphics Output |
DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b |
| Xe-cores |
4 |
| Max Resolution (HDMI) |
4K @ 60Hz (HDMI 2.1 TMDS) 8K @ 60Hz (HDMI2.1 FRL) |
| Max Resolution (DP)‡ |
8K @ 60Hz |
| Max Resolution (eDP – Integrated Flat Panel)‡ |
4K @ 60Hz |
| DirectX* Support |
12 |
| OpenGL* Support |
4.5 |
| OpenCL* Support |
3 |
| Intel® Quick Sync Video |
Yes |
| # of Displays Supported |
4 |
| Intel® Deep Learning Boost (Intel® DL Boost) on GPU |
Yes |
| NPU Name |
Intel® AI Boost |
| NPU Peak TOPS (Int8) |
13 |
| Sparsity Support |
Yes |
| Windows Studio Effects Support |
Yes |
| AI Software Frameworks Supported by NPU |
OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN |
| Direct Media Interface (DMI) Revision |
4 |
| Max # of DMI Lanes |
8 |
| Intel® Thunderbolt™ 4 |
Yes |
| Scalability |
1S Only |
| PCI Express Revision |
5.0 and 4.0 |
| PCI Express Configurations |
Up to 1×16+2×4, 2×8+2×4, 1×8+4×4 |
| Max # of PCI Express Lanes |
24 |
| Sockets Supported |
FCLGA1851 |
| Thermal Solution Specification |
PCG 2020A |
| Max Operating Temperature |
105 °C |
| Intel® Volume Management Device (VMD) |
Yes |
| Intel® Gaussian & Neural Accelerator |
3.5 |
| Intel® Thread Director |
Yes |
| Intel® Speed Shift Technology |
Yes |
| Intel® Thermal Velocity Boost |
Yes |
| Intel® Turbo Boost Max Technology 3.0 |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel® 64 |
Yes |
| Instruction Set |
64 Bit |
| Instruction Set Extensions |
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Idle States |
Yes |
| Enhanced Intel SpeedStep® Technology |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Intel vPro® Eligibility |
Intel vPro® Enterprise, Intel vPro® Platform |
| Intel® Threat Detection Technology (TDT) |
Yes |
| Intel® Active Management Technology (AMT) |
Yes |
| Intel® Standard Manageability (ISM) |
Yes |
| Intel® Remote Platform Erase (RPE) |
Yes |
| Intel® One-Click Recovery |
Yes |
| Intel® Hardware Shield Eligibility |
Yes |
| Intel® Control-Flow Enforcement Technology |
Yes |
| Intel® Total Memory Encryption – Multi Key |
Yes |
| Intel® AES New Instructions |
Yes |
| Secure Key |
Yes |
| Intel® Trusted Execution Technology |
Yes |
| Execute Disable Bit |
Yes |
| Intel® OS Guard |
Yes |
| Intel® Boot Guard |
Yes |
| Mode-based Execute Control (MBEC) |
Yes |
| Intel® Stable IT Platform Program (SIPP) |
Yes |
| Intel® Virtualization Technology with Redirect Protection (VT-rp) |
Yes |
| Intel® Virtualization Technology (VT-x) |
Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel® VT-x with Extended Page Tables (EPT) |
Yes |
| Warranty |
3 Years |
| Note** |
**Prices, Specifications & Features are subject to change without notice |
