Specifications
| Chipset | AMD B650 |
| CPU | Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors |
| Memory | 4x DDR5 UDIMM, Maximum Memory Capacity 256GB |
| Memory Support | DDR5 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz |
| Memory Features | Supports Dual-Channel mode, non-ECC, un-buffered memory, AMD EXPO Max overclocking frequency: 1DPC 1R Max speed up to 7200+ MHz 1DPC 2R Max speed up to 6000+ MHz 2DPC 1R Max speed up to 6000+ MHz 2DPC 2R Max speed up to 5400+ MHz |
| Onboard Graphics | 1x HDMI (HDMI 2.1, max resolution of 4K 60Hz), 1x DisplayPort (DP 1.4, max resolution of 4K 60Hz) |
| Slots | 1x PCI-E x16 slot Supports x16 (For Ryzen 9000 and 7000 Series processors) Supports x8 (For Ryzen 7 8700G and Ryzen 5 8600G processors) Supports x4 (For Ryzen 5 8500G processor) 2x PCI-E x1 slot PCI_E1 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E2 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset) |
| Audio | Realtek ALC897 Codec 7.1-Channel High Definition Audio |
| Storage | 2x M.2: M.2_1 Source (From CPU) supports up to PCIe 4.0 x4, supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4, supports 2280/2260 devices 4x SATA 6G M2_2 supports PCIe 4.0 x2 speed when Ryzen 5 8500G is installed |
| RAID | Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices Supports RAID 0, RAID 1 for M.2 NVMe storage devices |
| USB | 4x USB 2.0 (Front) 4x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 3x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Rear) 1x USB 10Gbps Type C (Front) |
| LAN | Realtek RTL8125BG 2.5Gbps LAN |
| Internal I/O | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 3x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector (JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 2x RGB LED connector (JRGB) 1x TPM pin header (Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports |
| Wireless LAN & Bluetooth | AMD Wi-Fi 6E Wireless module pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX Supports 20MHz, 40MHz, 80MHz, 160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands Supports 802.11 a/b/g/n/ac/ax Supports Bluetooth 5.3** |
| LED Feature | 4x EZ Debug LED |
| Back Panel Ports | DisplayPort 2.5G LAN USB 3.2 Gen 2 10Gbps (Type-A) USB 3.2 Gen 1 5Gbps (Type-A) Wi-Fi / Bluetooth Flash BIOS Button HDMI USB 3.2 Gen 2 10Gbps (Type-A) USB 3.2 Gen 2 10Gbps (Type-C) Audio connectors |
| Operating System | Support for Windows 11 64-bit, Windows 10 64-bit |
| PCB Info | mATX 243.84mm x 243.84mm |
Key Features
- AMD B650 chipset with support for Ryzen 7000, 8000 and 9000 series desktop processors.
- DDR5 memory up to 7200+ MHz (OC) across 4 DIMM slots, maximum capacity 256 GB.
- PCIe 4.0 ×16 slot for graphics cards (full x16 bandwidth with Ryzen 7000/9000 CPUs).
- Dual M.2 slots supporting PCIe 4.0 ×4 NVMe SSDs for high‑speed storage.
- 2.5 Gbps Ethernet (Realtek RTL8125BG) plus built‑in AMD Wi‑Fi 6E and Bluetooth 5.3 for fast wired and wireless connectivity.
- USB 10 Gbps ports – one Type‑C and multiple Type‑A rear ports for rapid data transfer.
- 4K60 video output via HDMI 2.1 and DisplayPort 1.4, complemented by Realtek ALC897 7.1‑channel audio.
