Specifications
| Model Name | SPATIUM M470 PRO PCIe 4.0 NVMe M.2 |
| Capacity | 1TB |
| Controller | PHISON E27T |
| Flash Memory | 3D NAND |
| Form Factor | M.2 2280 |
| Interface | PCIe Gen4 x4, NVMe 1.4 |
| Compatibility | PCIe Gen4/Gen3/Gen2/Gen1 |
| Dimensions | 80.00mm (L) x 22.00mm (W) x 2.15mm (H) |
| Sequential Read up to (MB/s) | 6000 |
| Sequential Write up to (MB/s) | 4500 |
| Random Read up to 4KB (IOPS) | 950,000 |
| Random Write up to 4KB (IOPS) | 950,000 |
| Maximum Operating Power (W) | 4.5 |
| PS3 Idle Power (mW) | 50 |
| Low Power L1.2 (mW) | 5 |
| Operating Temperatures | 0°C – 70°C |
| Storage Temperatures | -40°C – 85°C |
| Terabytes Written (TBW) | 320 |
| Mean Time Between Failure (MTBF) | Up to 1,500,000 Hours |
| Limited Warranty | 5 Years, or the coverage for the maximum TBW as stated, whichever comes first. |
| Advanced Features | TRIM (Performance Optimization, OS Support required) SMART (Self-Monitoring, Analysis and Reporting Technology) LDPC (Low Density Parity Check) ECC Algorithm End to End Data Path Protection APST (Autonomous Power State Transition) Pyrite (Encryption, Data Security) |
Key Features
- PCIe 4.0 x4 NVMe 1.4 Interface — Delivers sequential reads up to 6000 MB/s and writes up to 4500 MB/s
- High Random Performance — Up to 950,000 IOPS for both 4KB random read and write operations
- 1TB Capacity with 3D NAND & Phison E27T Controller — Optimized for speed, efficiency, and reliability
- Endurance & Reliability — 320 TBW rating and up to 1,500,000 hours MTBF
- 5-Year Limited Warranty — Covers 5 years or maximum TBW, whichever comes first
- Advanced Data Protection — LDPC ECC, End-to-End Data Path Protection, and Pyrite encryption support
- M.2 2280 Form Factor — Compact 80mm x 22mm x 2.15mm design with low power consumption (4.5W max, 50mW idle)
