Specifications
| Product | NVIDIA RTX 4000 Ada Generation |
| Architecture | NVIDIA Ada Lovelace Architecture |
| Foundry | TSMC |
| Process Size | 4 nm NVIDIA Custom Process |
| Transistors | 35.8 billion |
| Die Size | 294.5 mm 2 |
| CUDA Parallel Processing Cores | 6,144 |
| NVIDIA Tensor Cores | 192 |
| NVIDIA RT Cores | 48 |
| Single-Precision Performance 1 | 26.7 TFLOPS |
| RT Core Performance 1 | 61.8 TFLOPS |
| Tensor Performance 1 | 327.6 TFLOPS 2 |
| GPU Memory | 20 GB GDDR6 with ECC |
| Memory Interface | 160-bit |
| Memory Bandwidth | 360 GB/s |
| Max Power Consumption | 130W |
| Graphics Bus | PCI Express 4.0 x16 |
| Display Connectors | DP 1.4a (4) 3 |
| Form Factor | 4.4″ (H) x 9.5″(L) Single Slot |
| Product Weight | 528 g |
| Thermal Solution | Blower Active Fan |
| NVIDIA 3D Vision ® and 3D Vision Pro | Support via 3-pin mini DIN |
| Frame Lock | Compatible (with Quadro Sync II) |
| NVLink | Not Supported |
| NVENC | NVDEC | 2x | 2x (+AV1 Encode & Decode) |
| Warranty | 3 Years |
Key Features
- 6,144 CUDA cores delivering up to 26.7 TFLOPS single‑precision performance.
- 20 GB GDDR6 memory with ECC, 160‑bit interface and 360 GB/s bandwidth for large, error‑checked workloads.
- NVIDIA Ada Lovelace architecture built on a 4 nm TSMC process with 35.8 billion transistors.
- 48 RT cores and 192 Tensor cores providing 61.8 TFLOPS ray‑tracing and 327.6 TFLOPS AI acceleration.
- PCI Express 4.0 x16 connectivity and four DisplayPort 1.4a outputs for high‑resolution multi‑monitor setups.
- 130 W max power consumption with a blower‑style active cooling solution in a compact single‑slot form factor (4.4″ H × 9.5″ L, 528 g).
- 3‑year warranty for peace of mind.
