INTERNAL SSD

SAMSUNG 870 QVO 4TB SATA SSD

Compare

Application: Client PCs
Capacity: 4,000 GB (1 GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor: 2.5 inch
Interface: SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface
Dimension (WxHxD): 100 X 69.85 X 6.8 (mm)
Weight: Approx. 54.0g
Storage Memory: Samsung V-NAND 4bit MLC
Controller: Samsung MKX Controller
Cache Memory: Samsung 4 GB Low Power DDR4 SDRAM
TRIM Support: Yes

Specifications

Application	Client PCs
Capacity	4,000 GB (1 GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor	2.5 inch
Interface	SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface
Dimension (WxHxD)	100 X 69.85 X 6.8 (mm)
Weight	Approx. 54.0g Weight
Storage Memory	Samsung V-NAND 4bit MLC
Controller	Samsung MKX Controller
Cache Memory	Samsung 4 GB Low Power DDR4 SDRAM
TRIM Support	Yes
S.M.A.R.T Support	Yes
GC (Garbage Collection)	Auto Garbage Collection Algorithm
Encryption Support	AES 256-bit Encryption (Class 0),TCG/Opal, IEEE1667 (Encrypted drive)
WWN Support	World Wide Name supported
Device Sleep Mode Support	Yes
Sequential Read	Up to 560 MB/s Sequential Read * Performance may vary based on system hardware & configuration
Sequential Write	Up to 530 MB/s Sequential Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Read (4KB, QD32)	Up to 98,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Write (4KB, QD32)	Up to 88,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Read (4KB, QD1)	Up to 11,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Write (4KB, QD1)	Up to 35,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Average Power Consumption (system level)	Average: 3.2 W Maximum: 5.5 W (Burst mode) Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle)	Max. 35 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage	5V ± 5% Allowable voltage
Reliability (MTBF)	1.5 Million Hours Reliability (MTBF)
Operating Temperature	0 – 70 ? Operating Temperature
Shock	1,500 G & 0.5 ms (Half sine)
Software	Management SW
Warranty	3 Years

Key Features

4TB Capacity – Massive storage space for games, media, and applications
Samsung V-NAND 4bit MLC – Reliable and efficient storage memory technology
Up to 560 MB/s Sequential Read – Fast data access for improved system performance
Up to 530 MB/s Sequential Write – Quick file transfers with Intelligent TurboWrite technology
Up to 98,000 IOPS Random Read – Responsive performance for multitasking and demanding applications
SATA 6 Gb/s Interface – Backward compatible with SATA 3 Gb/s and SATA 1.5 Gb/s
AES 256-bit Encryption – Secure data protection with TCG/Opal and IEEE1667 support
3-Year Warranty – Trusted Samsung reliability with comprehensive support

SKU: 102435 Category: INTERNAL SSD

Application	Client PCs
Capacity	4,000 GB (1 GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor	2.5 inch
Interface	SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface
Dimension (WxHxD)	100 X 69.85 X 6.8 (mm)
Weight	Approx. 54.0g Weight
Storage Memory	Samsung V-NAND 4bit MLC
Controller	Samsung MKX Controller
Cache Memory	Samsung 4 GB Low Power DDR4 SDRAM
TRIM Support	Yes
S.M.A.R.T Support	Yes
GC (Garbage Collection)	Auto Garbage Collection Algorithm
Encryption Support	AES 256-bit Encryption (Class 0),TCG/Opal, IEEE1667 (Encrypted drive)
WWN Support	World Wide Name supported
Device Sleep Mode Support	Yes
Sequential Read	Up to 560 MB/s Sequential Read * Performance may vary based on system hardware & configuration
Sequential Write	Up to 530 MB/s Sequential Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Read (4KB, QD32)	Up to 98,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Write (4KB, QD32)	Up to 88,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Read (4KB, QD1)	Up to 11,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Write (4KB, QD1)	Up to 35,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Average Power Consumption (system level)	Average: 3.2 W Maximum: 5.5 W (Burst mode) Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle)	Max. 35 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage	5V ± 5% Allowable voltage
Reliability (MTBF)	1.5 Million Hours Reliability (MTBF)
Operating Temperature	0 – 70 ? Operating Temperature
Shock	1,500 G & 0.5 ms (Half sine)
Software	Management SW
Warranty	3 Years
