Specifications
| Chipset | AMD® B850 |
| CPU Support | Supports AMD Socket AM5 Processors including Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors |
| Memory Support | 4x DIMMS, Dual Channel DDR5, Maximum Memory Capacity 256GB (4x 64GB), up to 8000 MHz(OC) |
| PCI-E Expansion Slots | 1x PCIe 5.0 x16, 1x PCIe 4.0 x4 in 16x slot |
| Display Connector | DisplayPort x1, HDMI x1 |
| Audio | Realtek® ALC897 HD Audio, 5.1 Channel |
| Network | Realtek® RTL8125BG 2.5 Gigabit Ethernet M.2 WiFi 6 Module, Support 802.11 a/b/g/n/ac/ax, 2.4 GHz/ 5 GHz band, Bluetooth 5.3 Support |
| Front USB Headers | 1x USB 3.2 Gen1 (1 x Type-C), 1x USB 3.2 Gen1 (2 x Type-A), 1x USB 2.0 (2 x Type-A) |
| Rear Ports | 1× DisplayPort, 1× HDMI™, 1× RJ45 LAN, 2× Wi-Fi Antenna One-click Flash BIOS Button, 4× USB 2.0, 3× USB 3.2 Gen2 Type-A 1× USB 3.2 Gen2 Type-C, 3× Audio Jacks |
| Storage | 1x PCIe 5.0 M.2, 1x PCIe 4.0 M.2, 4x SATA |
| Dimensions | Micro-ATX, 244x244mm |
| Debug LED | DRAM: Yellow, CPU: Red, GPU: White, Boot: Green |
Key Features
- Chipset & CPU Support: AMD B850 chipset with AM5 socket, compatible with Ryzen™ 9000 / 8000 / 7000 series desktop processors.
- Memory: 4× DDR5 DIMMs, dual‑channel, up to 256 GB (4×64 GB) and speeds up to 8000 MHz (OC).
- PCIe Expansion: 1× PCIe 5.0 x16 slot + 1× PCIe 4.0 x4 (in x16 form factor) for graphics and storage cards.
- Storage: 1× PCIe 5.0 M.2, 1× PCIe 4.0 M.2, and 4× SATA ports.
- USB & Front Panel: Rear: 1× USB 3.2 Gen2 Type‑C, 3× USB 3.2 Gen2 Type‑A, 4× USB 2.0; Front headers: 1× USB 3.2 Gen1 Type‑C, 2× USB 3.2 Gen1 Type‑A, 2× USB 2.0.
- Networking: Realtek RTL8125BG 2.5 Gb Ethernet + Wi‑Fi 6 (802.11ax) module with Bluetooth 5.3.
- Video & Audio: DisplayPort + HDMI outputs, Realtek ALC897 5.1‑channel HD audio, debug LEDs (DRAM‑Yellow, CPU‑Red, GPU‑White, Boot‑Green) and one‑click flash BIOS button.
