Specifications
| SKU | 11349-02-20G |
| GPU Model | SAPPHIRE PURE AMD Radeon™ RX 9070 |
| Architecture | AMD RDNA™ 4 |
| Engine Clock | Boost Clock: Up to 2700 MHz Game Clock: Up to 2210 MHz |
| Stream Processors | 3584 |
| Compute Units | 56 CUs (3rd Gen RT + 2nd Gen AI Accelerators) |
| Infinity Cache | 64MB |
| Ray Accelerators | 56 |
| AI Accelerators | 112 |
| Memory Size & Bus | 16GB GDDR6 / 256-bit |
| Memory Clock | 20 Gbps Effective |
| Max Displays | 4 |
| Max Resolution | HDMI®: 7680×4320DisplayPort™ 2.1a: 7680×4320 |
| Interface | PCI-Express 5.0 x16 |
| Outputs | 2x HDMI®2x DisplayPort™ 2.1a |
| BIOS Support | UEFI |
| Game Index | 4K |
| Power Consumption | 245W Typical Board Power |
| Minimum PSU Requirement | 650W |
| Power Connector | 2 x 8-pin |
| Form Factor | 3 slot, ATX |
| Dimensions | 320mm (L) x 120.25mm (W) x 61.6mm (H) |
| Cooling System | Tri-X Cooling Technology |
| Fan Type | Two-Ball Bearing Fans |
| Sapphire Features | Honeywell PTM7950 TIM, Aero Curve Fan Blade, Free Flow, Frame Defense, Integrated Cooling Module, High TG Copper PCB, Optimized Composite Heat pipes, Metal Backplate, ARGB SAPPHIRE Logo, 12-Phase Digital Power Design, Fuse Protection, Intelligent Fan Control, Precision Fan Control |
| Software & Technologies | AMD HYPR-RX with AFMF 2, AMD Fidelity FX™ Super Resolution 4 with AI Upscaling, AMD Fluid Motion Frames 2, AMD Radeon™ Anti-Lag 2, AMD Noise Suppression, AMD Freesync™, AMD Smart Technologies, Microsoft® DirectX® 12 Ultimate, AMD Software: Adrenalin Edition™ |
| Operating Systems | Linux®, Windows® 10 & 11 (64-bit required) |
| Bundled Accessories | L-Shape Support Bracket, 3pin 5V ARGB Cable |
| Warranty | 3 Years |
Key Features
- AMD RDNA 4 GPU with 3584 stream processors and 56 compute units delivering high performance for 4K gaming.
- Boost clock up to 2700 MHz and game clock up to 2210 MHz for fast frame rates.
- 16GB GDDR6 memory on a 256‑bit bus with 64MB Infinity Cache and 20 Gbps effective clock for smooth 8K gameplay.
- PCI‑Express 5.0 x16 interface and dual HDMI 2.1a + DisplayPort 2.1a outputs supporting up to 4 displays at 7680×4320.
- Tri‑X Cooling Technology with two‑ball bearing fans, metal backplate and optimized heat pipes to keep temperatures low.
- 12‑phase digital power design and 245W TDP with dual 8‑pin connectors; recommended 650W PSU.
- 3‑year warranty with ARGB lighting, L‑shape support bracket and comprehensive software suite including AMD HYPR‑RX and FidelityFX Super Resolution 4.
