Specifications
| GPU | NVIDIA® GeForce RTX™ 5070 |
| CUDA Cores | 6144 |
| Video Memory | 12GB GDDR7 |
| Memory Bus | 192-bit |
| Engine Clock | 2512 MHz |
| Memory Clock | 28 Gbps |
| Interface | PCI Express 5.0 x16 |
| Display Outputs | 3x DisplayPort 2.1b with UHBR20 (up to 4K 480Hz or 8K 165Hz with DSC)1x HDMI 2.1b (4K 480Hz HDR / 8K 120Hz HDR with DSC & Gaming VRR) |
| HDCP Support | 2.3 |
| Multi-Display Capability | Quad Display (4 Displays) |
| Recommended PSU | 650W |
| Power Consumption | 250W |
| Power Input | 1x 12V-2×6 Power Connector |
| DirectX Support | Microsoft DirectX® 12 Ultimate |
| OpenGL Support | 4.6 |
| Cooling Solution | IceStorm 2.0 |
| Slot Size | 2-slot |
| SLI Support | No |
| Supported OS | Windows 11 / Windows 10 64-bit (v1809 or later) |
| Card Dimensions | 241.5 × 120.1 × 40.6 mm (9.5″ × 4.7″ × 1.6″) |
| Accessories | User Manual2x 8-pin to 16-pin Adapter Cables |
Key Features
- NVIDIA GeForce RTX 5070 GPU with 6144 CUDA cores
- 12GB GDDR7 video memory on a 192‑bit bus
- Boost engine clock up to 2512 MHz
- Memory speed 28 Gbps effective
- PCI Express 5.0 x16 interface for maximum bandwidth
- Triple DisplayPort 2.1b + HDMI 2.1b supporting up to 4K 480Hz / 8K 120Hz with DSC
- IceStorm 2.0 dual‑fan cooling in a compact 2‑slot design (241.5 mm length)
- Typical power draw 250W; recommended 650W PSU, powered via a single 12V‑2×6 connector
