Specifications
| GPU | NVIDIA® GeForce RTX™ 5070 Ti |
| CUDA Cores | 8960 |
| Video Memory | 16GB GDDR7 |
| Memory Bus | 256-bit |
| Engine Clock | 2512 MHz |
| Memory Clock | 28 Gbps |
| PCI Express | PCI Express 5.0 x16 |
| Display Outputs | 3x DisplayPort 2.1b (UHBR20) |
| HDCP Support | 2.3 |
| Multi Display Support | Quad Display |
| Recommended PSU | 750W |
| Power Consumption | 300W *High power consumption—check PSU manual before installation. |
| Power Input | 1x 12V-2×6 power input |
| DirectX Version | Microsoft DirectX® 12 Ultimate |
| OpenGL Version | 4.6 |
| Cooling System | IceStorm 3.0 |
| Slot Size | 3.5 Slot |
| SLI Support | No |
| Supported OS | Windows 11 / Windows 10 64-bit (v1809 or later) |
| Card Dimensions | 332.1mm x 137.5mm x 69.6mm (13.1″ x 5.4″ x 2.7″) |
| Accessories | User Manual, 3x 8-pin-to-16-pin cable, SPECTRA LINK cable, GPU Support Stand |
Key Features
- NVIDIA GeForce RTX 5070 Ti GPU with 8960 CUDA Cores
- 16GB GDDR7 video memory on a 256-bit bus
- Boost clock up to 2512 MHz and memory speed of 28 Gbps
- PCI Express 5.0 x16 interface for maximum bandwidth
- Triple DisplayPort 2.1b (UHBR20) outputs supporting quad‑display setup
- IceStorm 3.0 cooling system with a 3.5‑slot design
- 300W power draw; requires 1x 12V‑2×6 connector and a recommended 750W PSU
- Includes GPU support stand, SPECTRA LINK cable, and 3x 8‑pin‑to‑16‑pin adapters
