Specifications
| GPU | NVIDIA GeForce RTX™ 5090 |
| CUDA® Cores | 21760 |
| Video Memory | 32GB GDDR7 |
| Memory Bus | 512-bit |
| Engine Clock | 2422 MHz |
| Memory Clock | 28 Gbps |
| PCI Express | PCI Express 5.0 x16 |
| Display Outputs | – 3 × DisplayPort 2.1b with UHBR20 (Supports up to 4K 480Hz or 8K 165Hz with DSC) – 1 × HDMI 2.1b (Supports 4K 120Hz HDR, 8K 60Hz HDR, and Variable Refresh Rate) |
| HDCP Support | 2.3 |
| Multi-Display Capability | Quad Display |
| Recommended Power Supply | 1000W |
| Power Consumption | 575W (High power consumption, please carefully read your PSU manual before installation.) |
| Power Input | 1 × 12V-2×6 power input |
| DirectX | Microsoft DirectX® 12 Ultimate |
| OpenGL | 4.6 |
| Cooling | IceStorm 3.0 |
| Slot Size | 3.5 |
| SLI | No |
| Supported OS | Windows 11 / Windows 10 64-bit (v1809 November 2018 or later) |
| Card Dimensions | 329.7mm × 137.8mm × 67.8mm (13″ × 5.4″ × 2.7″) |
| Accessories | – User Manual – 4 × 8-pin-to-16-pin cable – SPECTRA LINK cable – GPU Support Stand |
| Warranty | 3 years + Additional 2 years after Registration |
Key Features
- GPU: NVIDIA GeForce RTX™ 5090 with 21,760 CUDA cores
- Memory: 32GB GDDR7 video memory on a 512-bit bus
- Clock Speeds: Boost clock up to 2,422 MHz; memory speed 28 Gbps
- Interface: PCI Express 5.0 x16 for maximum bandwidth
- Display Outputs: 3 × DisplayPort 2.1b (UHBR20) + 1 × HDMI 2.1b, supporting up to 8K resolution
- Cooling: IceStorm 3.0 cooling system in a 3.5-slot design
- Power: 575W TDP; recommends 1000W PSU with 1×12V-2×6 power input
- Warranty: 3-year limited warranty, extendable to 5 years with product registration
