Specifications
| GPU | NVIDIA® GeForce RTX™ 5070 Ti |
| CUDA Cores | 8960 |
| Video Memory | 16GB GDDR7 |
| Memory Bus | 256-bit |
| Memory Clock | 28 Gbps |
| Engine Clock | 2452 MHz |
| Bus Interface | PCI Express 5.0 x16 |
| Display Outputs | 3x DisplayPort 2.1b with UHBR201x HDMI 2.1b (Supports 4K 480Hz / 8K 120Hz HDR, VRR) |
| HDCP Support | 2.3 |
| Multi Display Capability | Quad Display (4 monitors) |
| Maximum Resolution | 7680 × 4320 (8K) |
| DirectX Support | Microsoft DirectX® 12 Ultimate |
| OpenGL Support | 4.6 |
| Cooling System | IceStorm 2.0 |
| Slot Size | 2-slot |
| Power Consumption | 300W ⚠️ High power draw – check PSU compatibility |
| Recommended PSU | 750W |
| Power Input | 1x 12V-2×6 Connector |
| SLI Support | No |
| Supported OS | Windows 11 / 10 (64-bit, v1809 or later) |
| Card Dimensions (L × W × H) | 304.4 × 115.8 × 41.6 mm (12″ × 4.6″ × 1.6″) |
| Accessories Included | – User Manual- 2x 8-pin to 16-pin Cables- GPU Support Stand |
Key Features
- NVIDIA GeForce RTX 5070 Ti GPU with 8960 CUDA Cores
- 16GB GDDR7 video memory on a 256‑bit bus, 28 Gbps memory clock
- Boost engine clock up to 2452 MHz
- PCI Express 5.0 x16 interface for maximum bandwidth
- Triple DisplayPort 2.1b + HDMI 2.1b outputs supporting 4K@480Hz / 8K@120Hz HDR & VRR
- IceStorm 2.0 dual‑fan cooling in a compact 2‑slot design (304.4 mm × 115.8 mm × 41.6 mm)
- 300W power draw; requires 1x 12V‑2×6 connector and a recommended 750W PSU
