AMD RYZEN 5 8500G 6 CORES UPTO 5 GHZ AM5 PROCESSOR

AMD RYZEN 5 8500G 6 CORES UPTO 5 GHZ AM5 PROCESSOR

Compare

The AMD Ryzen 5 8500G is a 6-core desktop processor featuring a hybrid architecture of 2 “Zen 4” and 4 “Zen 4c” cores. It delivers boost clock speeds up to 5.0 GHz on the AM5 platform. This 8000 G-Series processor includes integrated Radeon graphics for high-performance consumer use.

Specifications

Model AMD Ryzen 5 8500G
Platform Desktop
Product Family AMD Ryzen Processors
Product Line AMD Ryzen 5 8000 G-Series Desktop Processors with Radeon Graphics
AMD PRO Technologies No
Consumer Use Yes
Regional Availability Global
Former Codename “Phoenix”
Architecture 2 x “Zen4”, 4 x “Zen4c”
# of CPU Cores 6
Multithreading (SMT) Yes
# of Threads 12
Max. Boost Clock Up to 5.0GHz
Base Clock 3.5GHz
Max Zen4c Clock Up to 3.7GHz
Zen4 Base Clock 4.1GHz
Zen4c Base Clock 3.2GHz
L2 Cache 6MB
L3 Cache 16MB
Default TDP 65W
AMD Configurable TDP (cTDP) 45-65W
Processor Technology for CPU Cores TSMC 4nm FinFET
CPU Compute Die (CCD) Size 137mm²
Package Die Count 1
Unlocked for Overclocking Yes
AMD EXPO Memory Overclocking Technology Yes
Precision Boost Overdrive Yes
Curve Optimizer Voltage Offsets Yes
AMD Ryzen Master Support Yes
CPU Socket AM5
CPU Boost Technology Precision Boost 2
Instruction Set x86-64
Supported Extensions AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Max. Operating Temperature (Tjmax) 95°C
*OS Support Windows 11 – 64-Bit Edition Windows 10 – 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit *Operating System (OS) support will vary by manufacturer.
Native USB 4 (40Gbps) Ports 2
Native USB 3.2 Gen 2 (10Gbps) Ports 2
Native USB 2.0 (480Mbps) Ports 1
PCI Express Version PCIe 4.0
Native PCIe Lanes (Total/Usable) 14 / 10
NVMe Support Boot, RAID0, RAID1
System Memory Type DDR5
Memory Channels 2
Max. Memory 256GB
System Memory Subtype UDIMM
Max Memory Speed 2x1R DDR5-5200 2x2R DDR5-5200 4X1R DDR5-3600 4x2R DDR5-3600
Integrated Graphics Yes
Graphics Model AMD Radeon 740M
Graphics Core Count 4
Graphics Frequency 2800 MHz
DirectX Version 2.1
DisplayPort Extensions HDR Metadata Adaptive-Sync UHBR10
DisplayPort Max Refresh Rates (SDR) 7680×4320 @ 60Hz 3840×2160 @ 240Hz 3440×1440 @ 360Hz 2560×1440 @ 480Hz 1920×1080 @ 600Hz
DisplayPort Max Refresh Rates (HDR) 7680×4320 @ 60Hz 3840×2160 @ 240Hz 3440×1440 @ 360Hz 2560×1440 @ 480Hz 1920×1080 @ 600Hz
HDMI Version 2.1
HDCP Version Supported 2.3
USB Type-C DisplayPort Alternate Mode Yes
Multi-Monitor Support Yes
Max Displays 4
AMD FreeSync Yes
Wireless Display Miracast
Max Video Encode Bandwidth (SDR) 1080p630 8bpc H.264, 1440p373 8bpc H.264, 2160p175 8bpc H.264, 1080p630 8bpc H.265, 1440p373 8bpc H.265, 2160p175 8bpc H.265, 4320p43 8bpc H.265, 1080p864 8/10bpc AV1 1440p513 8/10bpc AV1, 2160p240 8/10bpc AV1 4320p60 8/10bpc AV1
Max Video Decode Bandwidth 1080p60 8bpc MPEG2, 1080p60 8bpc VC1, 1080p786 8/10bpc VP9, 2160p196 8/10bpc VP9 4320p49 8/10bpc VP9, 1080p1200 8bpc H.264 2160p300 8bpc H.264, 4320p75 8bpc H.264 1080p786 8/10bpc H.265, 2160p196 8/10bpc H.265 4320p49 8/10bpc H.265, 1080p960 8/10bpc AV1 2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1
AMD SmartAccess Memory Yes
Warranty 3 Years

Key Features

  • 6 Cores / 12 Threads: Hybrid architecture with 2× Zen 4 and 4× Zen 4c cores
  • Max Boost Clock up to 5.0 GHz: Base clock 3.5 GHz for responsive performance
  • Integrated AMD Radeon 740M Graphics: 4 compute units at 2800 MHz, supports up to 4 displays via HDMI 2.1 and DisplayPort
  • DDR5 Memory Support: Up to 256 GB, speeds up to 5200 MHz (2×1R) with AMD EXPO overclocking
  • AM5 Socket with PCIe 4.0 & USB4: 14 total PCIe lanes (10 usable), native USB4 40 Gbps ports
  • Unlocked for Overclocking: Precision Boost Overdrive, Curve Optimizer, and AMD Ryzen Master support
  • Efficient 65W TDP: Configurable cTDP 45–65 W for flexible power management
  • 3-Year Warranty: Backed by AMD’s standard limited warranty
