| Name |
AMD Ryzen™ 7 8700G |
| Family |
Ryzen |
| Series |
Ryzen 8000 Series |
| Form Factor |
Desktops |
| AMD PRO Technologies |
No |
| Commercial Use |
Yes |
| Regional Availability |
Global |
| Former Codename |
Phoenix |
| Architecture |
Zen 4 |
| # of CPU Cores |
8 |
| Multithreading (SMT) |
Yes |
| # of Threads |
16 |
| Max. Boost Clock |
Up to 5.1GHz |
| Base Clock |
4.2GHz |
| L2 Cache |
8MB |
| L3 Cache |
16MB |
| Default TDP |
65W |
| AMD Configurable TDP (cTDP) |
45-65W |
| Processor Technology for CPU Cores |
TSMC 4nm FinFET |
| CPU Compute Die (CCD) Size |
178mm² |
| Package Die Count |
1 |
| AMD EXPO™ Memory Overclocking Technology |
Yes |
| Precision Boost Overdrive |
Yes |
| Curve Optimizer Voltage Offsets |
Yes |
| AMD Ryzen™ Master Support |
Yes |
| CPU Socket |
AM5 |
| CPU Boost Technology |
Precision Boost 2 |
| Instruction Set |
x86-64 |
| Supported Extensions |
AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 |
| Max. Operating Temperature (Tj-max) |
95°C |
| Launch Date |
1/31/2024 |
| *OS Support |
Windows 11 – 64-Bit Edition , Windows 10 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit |
| Native USB 4 (40Gbps) Ports |
2 |
| Native USB 3.2 Gen 2 (10Gbps) Ports |
2 |
| Native USB 2.0 (480Mbps) Ports |
1 |
| PCI Express® Version |
PCIe® 4.0 |
| Native PCIe® Lanes (Total/Usable) |
20 , 16 |
| NVMe Support |
Boot , RAID0 , RAID1 |
| System Memory Type |
DDR5 |
| Memory Channels |
2 |
| Max. Memory |
256 GB |
| System Memory Subtype |
UDIMM |
| Max Memory Speed |
2x1R DDR5-5200 2x2R DDR5-5200 4x1R DDR5-3600 4x2R DDR5-3600 |
| Graphics Model |
AMD Radeon™ 780M |
| Graphics Core Count |
12 |
| Graphics Frequency |
2900 MHz |
| DirectX® Version |
12 |
| DisplayPort™ Version |
2.1 |
| DisplayPort Extensions |
Adaptive-Sync , HDR Metadata , UHBR10 |
| DisplayPort Max Refresh Rates (SDR) |
7680×4320 @ 60Hz , 3840×2160 @ 240Hz , 3440×1440 @ 360Hz , 2560×1440 @ 480Hz , 1920×1080 @ 600Hz |
| DisplayPort Max Refresh Rates (HDR) |
7680×4320 @ 60Hz , 3840×2160 @ 240Hz , 3440×1440 @ 360Hz , 2560×1440 @ 480Hz , 1920×1080 @ 600Hz |
| HDMI® Version |
2.1 |
| HDCP Version Supported |
2.3 |
| USB Type-C® DisplayPort™ Alternate Mode |
Yes |
| Multi-Monitor Support |
Yes |
| Max Displays |
4 |
| AMD FreeSync™ |
Yes |
| Wireless Display |
Miracast |
| Max Video Encode Bandwidth (SDR) |
1080p630 8bpc H.264, 1440p373 8bpc H.264, 2160p175 8bpc H.264, 1080p630 8bpc H.265, 1440p373 8bpc H.265, 2160p175 8bpc H.265, 4320p43 8bpc H.265, 1080p864 8/10bpc AV1, 1440p513 8/10bpc AV1, 2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1 |
| Max Video Decode Bandwidth |
1080p60 8bpc MPEG2, 1080p60 8bpc VC1, 1080p786 8/10bpc VP9, 2160p196 8/10bpc VP9, 4320p49 8/10bpc VP9, 1080p1200 8bpc H.264, 2160p300 8bpc H.264, 4320p75 8bpc H.264, 1080p786 8/10bpc H.265, 2160p196 8/10bpc H.265, 4320p49 8/10bpc H.265, 1080p960 8/10bpc AV1, 2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1 |
| AMD SmartAccess Memory |
Available |
| Warranty |
3 Years |
