Specifications
| Graphics Engine | Intel® Arc B580 |
| Bus Standard | PCI® Express 4.0 x8 |
| DirectX Support | 12 Ultimate |
| OpenGL Support | 4.6 |
| Memory | 12GB GDDR6 |
| Engine Clock | 2740 MHz |
| Intel® XMX Engines | 160 |
| Compute Units | 20 |
| Memory Clock | 19 Gbps |
| Memory Interface | 192-bit |
| Max Digital Resolution | 7680 x 4320 |
| Display Outputs | 1x DisplayPort 2.1 (UHBR13.5) 2x DisplayPort 2.1 (UHBR10) 1x HDMI 2.1a |
| HDCP Support | Yes |
| Multi-view Support | 4 |
| Recommended PSU | 650W |
| Power Connector | 1x 8-pin |
| Accessories | 1x Quick Installation Guide |
| Dimensions (L x W x H) | 249 x 132 x 41 mm (2-slot) |
| Net Weight | 720 g |
| Warranty | 3 Years |
Key Features
- GPU: Intel® Arc B580
- Memory: 12GB GDDR6
- Engine Clock: 2740 MHz
- Memory Clock: 19 Gbps
- Display Outputs: 1x DisplayPort 2.1 (UHBR13.5), 2x DisplayPort 2.1 (UHBR10), 1x HDMI 2.1a
- Max Resolution: 7680 x 4320 (8K)
- Interface: PCI Express 4.0 x8
- Warranty: 3 Years
