Specifications
| Model | PRIME-RTX5070TI-16G |
| Graphic Engine | NVIDIA® GeForce RTX™ 5070 Ti |
| AI Performance | 1406 TOPs |
| Bus Standard | PCI Express 5.0 |
| OpenGL | OpenGL® 4.6 |
| Video Memory | 16GB GDDR7 |
| Engine Clock | OC mode: 2482MHz Default mode: 2452MHz (Boost Clock) |
| CUDA Cores | 8960 |
| Memory Speed | 28 Gbps |
| Memory Interface | 256-bit |
| Resolution | Digital Max Resolution 7680 x 4320 |
| Interface | – 1 x HDMI 2.1b (Native) – 3 x DisplayPort 2.1b (Native) |
| HDCP Support | Yes (2.3) |
| Maximum Display Support | 4 |
| NVLink/Crossfire Support | No |
| Accessories | – 1 x Speedsetup Manual – 1 x ASUS Velcro Hook & Loop – 1 x Thank You Card – 1 x Adapter Cable (1 to 3) |
| Software | ASUS GPU Tweak III, MuseTree, GeForce Game Ready Driver, Studio Driver (download from support site) |
| Dimensions | 304 x 126 x 50 mm (12 x 5 x 2 inches) |
| Recommended PSU | 750W |
| Power Connectors | 1 x 16-pin |
| Slot | 2.5 Slot |
| SFF Ready | Compatible |
| Warranty | 3 Years |
Key Features
- GPU: NVIDIA GeForce RTX 5070 Ti
- Memory: 16GB GDDR7, 28 Gbps speed, 256-bit interface
- CUDA Cores: 8960 for parallel processing
- Clock Speeds: OC mode up to 2482 MHz boost, Default 2452 MHz
- Interface: PCI Express 5.0 x16; 1× HDMI 2.1b + 3× DisplayPort 2.1b (supports 4× 8K displays)
- Power: 1× 16‑pin power connector, recommended 750W PSU
- Warranty & Build: 3‑year warranty, 2.5‑slot design (304×126×50 mm), SFF‑ready
