Specifications
| SKU | 11348-01-20G |
| GPU Model | SAPPHIRE NITRO+ AMD Radeon™ RX 9070 XT |
| Architecture | AMD RDNA™ 4 |
| Engine Clock | Boost Clock: Up to 3060 MHzGame Clock: Up to 2520 MHz |
| Stream Processors | 4096 |
| Compute Units | 64 CUs (3rd Gen RT + 2nd Gen AI Accelerators) |
| Infinity Cache | 64MB |
| Ray Accelerators | 64 |
| AI Accelerators | 128 |
| Memory Size & Bus | 16GB GDDR6 / 256-bit |
| Memory Clock | 20 Gbps Effective |
| Max Displays | 4 |
| Max Resolution | HDMI®: 7680×4320DisplayPort™ 2.1a: 7680×4320 |
| Interface | PCI-Express 5.0 x16 |
| Outputs | 2x HDMI®2x DisplayPort™ 2.1a |
| BIOS Support | UEFI |
| Game Index | 4K |
| Power Consumption | 330W Typical Board Power |
| Minimum PSU Requirement | 750W |
| Power Connector | 12V-2×6(H++) (Includes 3×8-pin power adapter) |
| Form Factor | 3.2 slot, ATX |
| Dimensions | 330.8mm (L) x 128.5mm (W) x 65.68mm (H) |
| Cooling System | Tri-X Cooling Technology |
| Fan Type | Two-Ball Bearing Fans |
| Sapphire Features | Quick Connect MagniPlate, STEALTH Hidden Power Cable, ARGB Light Bar, Cold Rolled Steel Frame, Honeywell PTM7950 TIM, Free Flow, FrameDefense, Optimized Composite Heatpipes, Fan Quick Connect, Premium 16-Phase Digital Power Design, Fuse Protection, Intelligent Fan Control, Precision Fan Control |
| Software & Technologies | AMD HYPR-RX with AFMF 2, AMD FidelityFX™ Super Resolution 4 with AI Upscaling, AMD Fluid Motion Frames 2, AMD Radeon™ Anti-Lag 2, AMD Noise Suppression, AMD Freesync™, AMD Smart Technologies, Microsoft® DirectX® 12 Ultimate, AMD Software: Adrenalin Edition™ |
| Operating Systems | Linux®, Windows® 10 & 11 (64-bit required) |
| Bundled Accessories | L-Shape Support Bracket, 3-pin 5V ARGB Cable, Magnetic Backplate, 12V-2×6(H++) to PCI Express 3×8-pin Power Adapter |
| Warranty | 3 Years |
Key Features
- AMD RDNA™ 4 architecture – 64 Compute Units, 4096 Stream Processors, 64 Ray Accelerators, 128 AI Accelerators
- Boost Clock up to 3060 MHz, Game Clock up to 2520 MHz
- 16 GB GDDR6 memory on a 256‑bit bus, 20 Gbps effective speed, 64 MB Infinity Cache
- Supports up to 4 displays at 8K (7680×4320) via HDMI 2.1 and DisplayPort 2.1a
- PCIe 5.0 x16 interface, Typical Board Power 330 W, requires minimum 750 W PSU, includes 12V‑2×6(H++) power connector with 3×8‑pin adapter
- Tri‑X Cooling with Two‑Ball Bearing fans, premium 16‑phase digital power design, Honeywell PTM7950 TIM, optimized composite heatpipes
- Sapphire exclusives: Quick Connect MagniPlate, STEALTH Hidden Power Cable, ARGB Light Bar, Cold Rolled Steel Frame, Free Flow, FrameDefense, Fan Quick Connect, Fuse Protection, Intelligent & Precision Fan Control
- 3‑year warranty; includes L‑shape support bracket, magnetic backplate, ARGB cable, power adapter
