Specifications
| Platform | INTEL |
| Socket | LGA1700 |
| Cpu Type | 14th Gen,13th Gen,12th Gen |
| Chipset | Z790 |
| Memory Speed | up to 7200+ |
| Max Memory Support | 128 GB |
| Supported Memory Type | DDR5 |
| Channel Supported | Dual Channel |
| Memory Feature | Supports Intel Extreme Memory Profile (XMP) OptiMem II * Supported memory types, data rate(Speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list. * Non-ECC, un-buffered DDR5 memory supports On-Die ECC function. |
| Graphics Port | 1 x HDMI,1 x DisplayPort |
| Expansion Slots | Intel 13th & 12th Gen Processors* 1 x PCIe 5.0 x16 slot Intel Z790 Chipset 3 x PCIe 4.0 x16 slots (support x4 mode) 1 x PCIe 3.0 x1 slot |
| Back Panel I/O Ports | 1 x USB 3.2 Gen 2×2 port (1 x USB Type-C) 1 x USB 3.2 Gen 2 port (1 x Type-A) 2 x USB 3.2 Gen 1 ports (2 x Type-A) 4 x USB 2.0 ports (4 x Type-A) 1 x DisplayPort 1 x HDMI port 1 x Wi-Fi Module 1 x Realtek 2.5Gb Ethernet port 3 x Audio jacks 1 x PS/2 Keyboard/Mouse combo port |
| Internal I/O Connector | Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 3 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector 1 x 4-pin +12V Power connector Storage related 3 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 2 connector (supports USB Type-C) 2 x USB 3.2 Gen 1 headers support 4 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 2 x Aura RGB headers 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x S/PDIF Out header 1 x SPI TPM header (14-1pin) 1 x 20-5pin System Panel header 1 x Thunderbolt (USB4) Header |
| Form Factor | ATX |
| Warranty | 3 Years |
Key Features
- CPU Support: Compatible with 12th, 13th, and 14th Gen Intel Core processors (LGA1700) on Intel Z790 chipset.
- Memory: DDR5 support, speeds up to 7200+ MT/s (OC), max 128 GB dual‑channel, XMP & OptiMem II ready.
- Expansion Slots: 1× PCIe 5.0 x16, 3× PCIe 4.0 x16 (x4 mode), 1× PCIe 3.0 x1.
- Storage: 3× M.2 slots (Key M) + 4× SATA 6Gb/s ports.
- Connectivity: Wi‑Fi module, Realtek 2.5 Gb Ethernet, USB 3.2 Gen 2×2 Type‑C, USB 3.2 Gen 2 Type‑A, 2× USB 3.2 Gen 1, 4× USB 2.0 rear ports.
- Video Output: HDMI and DisplayPort for integrated graphics.
- Form Factor & Warranty: ATX layout, backed by a 3‑year manufacturer warranty.
