Specifications
| Graphics Processing | GeForce RTX™ 5080 |
| Core Clock | 2730 MHz (Reference: 2617 MHz) |
| CUDA® Cores | 10,752 |
| Memory Clock | 30 Gbps |
| Memory Size | 16 GB |
| Memory Type | GDDR7 |
| Memory Bus | 256-bit |
| Card Bus | PCI Express 5.0 |
| Max Digital Resolution | 7680 x 4320 |
| Multi-view Support | 4 Displays |
| Card Size (mm) | 304 (L) x 126 (W) x 50 (H) |
| PCB Form | ATX |
| DirectX | DirectX 12 API |
| OpenGL | OpenGL 4.6 |
| Recommended PSU | 850W |
| Power Connectors | 1x 16-pin (12V-2×6) |
| Output Ports | 3x DisplayPort 2.1b1x HDMI 2.1b |
| Accessories | VGA Manual, Warranty Notice, 1x 12V-2×6 to 3x PCIe 8-pin Adapter, Versatile VGA Holder, VGA Holder Manual |
| Warranty | 3 Years |
Key Features
- GPU: NVIDIA GeForce RTX™ 5080
- Core Clock: Up to 2730 MHz (Reference 2617 MHz)
- CUDA Cores: 10,752
- Memory: 16 GB GDDR7, 30 Gbps effective, 256‑bit bus
- Interface: PCI Express 5.0 x16
- Display Outputs: 3× DisplayPort 2.1b + 1× HDMI 2.1b, max resolution 7680×4320, supports 4 displays
- Power & Warranty: 1× 16‑pin (12V‑2×6) connector, 850W PSU recommended, 3‑year warranty
