| Product Collection |
Intel Core™ Ultra Processors (Series 2) |
| Code Name |
Products formerly Arrow Lake |
| Total Cores |
10 |
| # of Performance-cores |
6 |
| # of Efficient-cores |
4 |
| # of Low Power Efficient-cores |
0 |
| Total Threads |
10 |
| Max Turbo Frequency |
4.9 GHz |
| Performance-core Max Turbo Frequency |
4.9 GHz |
| Efficient-core Max Turbo Frequency |
4.4 GHz |
| Performance-core Base Frequency |
3.3 GHz |
| Efficient-core Base Frequency |
2.7 GHz |
| Cache |
20 MB Intel Smart Cache |
| Total L2 Cache |
22 MB |
| Processor Base Power |
65 W |
| Maximum Turbo Power |
121 W |
| Intel Deep Learning Boost (Intel DL Boost) on CPU |
Yes |
| AI Software Frameworks Supported by CPU |
OpenVINO™ | WindowsML | DirectML | ONNX RT | WebNN |
| CPU Lithography |
TSMC N3B |
| Embedded Options Available |
No |
| Use Conditions |
PC/Client/Tablet |
| Datasheet |
View now |
| Max Memory Size (dependent on memory type) |
256 GB |
| Memory Types |
Up to DDR5 6400 MT/s |
| Max # of Memory Channels |
2 |
| ECC Memory Supported |
No |
| Graphics Output |
n/a |
| Xe-cores |
0 |
| Intel Quick Sync Video |
No |
| # of Displays Supported |
0 |
| NPU Name |
Intel AI Boost |
| NPU Peak TOPS (Int8) |
13 |
| Sparsity Support |
Yes |
| Windows Studio Effects Support |
Yes |
| AI Software Frameworks Supported by NPU |
OpenVINO™ | WindowsML | DirectML | ONNX RT | WebNN |
| Direct Media Interface (DMI) Revision |
4 |
| Max # of DMI Lanes |
8 |
| Intel Thunderbolt 4 |
Yes |
| Scalability |
1S Only |
| PCI Express Revision |
5.0 and 4.0 |
| PCI Express Configurations |
Up to 1×16+2×4 | 2×8+2×4 | 1×8+4×4 |
| Max # of PCI Express Lanes |
24 |
| Sockets Supported |
FCLGA1851 |
| Thermal Solution Specification |
PCG 2022C |
| Max Operating Temperature |
105 °C |
| Package Size |
45 mm x 37.5 mm |
| Intel Gaussian & Neural Accelerator |
3.5 |
| Intel Thread Director |
Yes |
| Intel Speed Shift Technology |
Yes |
| Intel Turbo Boost Technology |
2 |
| Intel Hyper-Threading Technology |
No |
| Intel 64 |
Yes |
| Instruction Set |
64-bit |
| Instruction Set Extensions |
Intel SSE4.1 | Intel SSE4.2 | Intel AVX2 |
| Idle States |
Yes |
| Enhanced Intel SpeedStep Technology |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Intel Volume Management Device (VMD) |
Yes |
| Intel Threat Detection Technology (TDT) |
Yes |
| Intel Active Management Technology (AMT) |
No |
| Intel Standard Manageability (ISM) |
Yes |
| Intel Remote Platform Erase (RPE) |
No |
| Intel One-Click Recovery |
No |
| Intel Secure Key |
Yes |
| Intel Control-Flow Enforcement Technology |
Yes |
| Intel Total Memory Encryption – Multi Key |
No |
| Intel AES New Instructions |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Execute Disable Bit |
Yes |
| Intel OS Guard |
Yes |
| Intel Boot Guard |
Yes |
| Mode-based Execute Control (MBEC) |
Yes |
| Intel Stable IT Platform Program (SIPP) |
No |
| Intel Virtualization Technology with Redirect Protection (VT-rp) |
No |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
