Specifications
| Platform | INTEL |
| Socket | LGA1151 |
| CPU Type | 9th Gen,8th Gen, Pentium, Celeron |
| Chipset | H310 |
| Memory Speed | up to 2666 |
| Max Memory Support | 32 GB |
| Supported Memory Type | DDR4 |
| Channel Supported | Dual Channel |
| Memory Feature | Dual channel memory architecture Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP) |
| Graphics Port | 1x VGA Port,1x DVI-D Port,1x HDMI |
| Expansion Slots | 1 x PCIe 3.0 x16 slot 2 x PCIe 2.0 x1 slots |
| Back Panel I/O Ports | PS/2 Combo Port VGA Port HDMI™ Port USB 3.1 Gen1 LAN Port HD Audio Connectors USB 2.0 Port DVI-D Port USB 2.0 Port |
| Internal I/O Connector | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) 1 x USB 2.0 connector (supports additional 2 USB 2.0 ports) 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector 1 x Front panel audio connector 1 x Serial port connector 2 x Front panel connectors 1 x TPM module connector 1 x Chassis Intrusion connector 1 x Clear CMOS jumper |
| Form Factor | Micro-ATX |
| Warranty | 3 Years |
Key Features
- Socket LGA1151 – Supports 9th Gen, 8th Gen Intel Core, Pentium and Celeron processors
- H310 Chipset – Stable platform for everyday computing
- DDR4 Memory – Up to 2666 MHz, dual‑channel, max 32 GB
- Integrated Graphics – VGA, DVI‑D and HDMI outputs for versatile display options
- Expansion Slots – 1× PCIe 3.0 x16 + 2× PCIe 2.0 x1 slots
- Storage & Connectivity – 4× SATA 6Gb/s, USB 3.1 Gen1 front‑panel header, Gigabit LAN, HD audio
- Micro‑ATX Form Factor & 3‑Year Warranty – Compact size with long‑term reliability
