Specifications
| Platform | AMD |
| Socket | AM5 |
| CPU Type | Ryzen 9000,Ryzen 8000,Ryzen 7000 |
| Chipset | B650 |
| Memory Speed | up to 7800+ |
| Max Memory Support | 128 GB |
| Supported Memory Type | DDR5 |
| Channel Supported | Dual Channel |
| Memory Feature | Supports non-ECC, un-buffered memory Supports AMD EXPO |
| Graphics Port | 1 x HDMI |
| Expansion Slots | 4x PCI-E x16 slot • Supports x16/x1/x1/x1 (For Ryzen™ 9000/ 7000 Series processors) • Supports x8/x1/x1/x1 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports x4/x1/x1/x1 (For Ryzen™ 8500/ 8300 Series processors) PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset) |
| Wireless Networking | WiFi 6E,Bluetooth 5.3 |
| Back Panel I/O Ports | HDMI™ USB 3.2 Gen 2 10Gbps (Type-A) USB 2.0 LAN port Wi-Fi / Bluetooth Audio connectors Flash BIOS Button USB 3.2 Gen 1 5Gbps (Type-A) |
| Internal I/O Connector | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 3x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 2x Addressable V2 RGB LED connector (JARGB_V2) 2x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 8x USB 2.0 ports 6x USB 5Gbps Type A ports 1x USB 5Gbps Type C ports 2x USB 10Gbps Type A ports |
| Form Factor | ATX |
| Warranty | 3 Years |
Key Features
- AM5 socket compatible with Ryzen 9000, 8000, and 7000 series processors
- B650 chipset supporting DDR5 memory up to 7800+ MT/s, max 128 GB (dual‑channel)
- Supports non‑ECC un‑buffered DDR5 and AMD EXPO memory overclocking
- Integrated Wi‑Fi 6E and Bluetooth 5.3 for wireless connectivity
- PCIe expansion: 1× PCIe 4.0 x16 (CPU) + 3× PCIe 3.0 x1 (chipset) slots
- Extensive USB I/O: 2× USB 3.2 Gen 2 10Gbps Type‑A (rear), 2× USB 3.2 Gen 2 10Gbps Type‑A (internal), 6× USB 3.2 Gen 1 5Gbps Type‑A, 1× USB 3.2 Gen 1 5Gbps Type‑C, 8× USB 2.0 ports plus HDMI output
- ATX form factor with Flash BIOS Button and 3‑year warranty
