Specifications
| CHIPSET | AMD B650 |
| CPU | Supports AMD Ryzen 8000/ 7000 Series Desktop Processors Socket AM5 |
| MEMORY | 2x DDR5, Maximum Memory Capacity 128GB Memory Support DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz Max. overclocking frequency: 1DPC 1R Max speed up to 6800+ MHz 1DPC 2R Max speed up to 6000+ MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports AMD EXPO |
| ONBOARD GRAPHICS | 1x HDMI Support HDMI TM 2.1, maximum resolution of 4K 60Hz* 1x VGA Support VGA, maximum resolution of 2048×1536 50Hz, 2048×1280 60Hz, 1920×1200 60Hz *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| SLOT | 1x PCI-E x16 slot Supports x16 (For Ryzen 7000 Series processors) Supports x8 (For Ryzen 7 8700G and Ryzen 5 8600G processors) Supports x4 (For Ryzen 5 8500G processor) 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) |
| STORAGE | 1x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G |
| RAID | Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices |
| USB | 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) |
| LAN | Realtek RTL8125BG 2.5G LAN |
| AUDIO | Realtek ALC897 Codec 7.1-Channel High Definition Audio |
| INTERNAL IO | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports |
| LED FEATURE | 4x EZ Debug LED |
| BACK PANEL PORTS | HDMI VGA Keyboard/Mouse USB 3.2 Gen 1 5Gbps (Type-A) LAN port Audio connectors USB 2.0 |
| OPERATING SYSTEM | Support for Windows 11 64-bit, Windows 10 64-bit |
| PCB INFO | mATX 215mmx243.84mm |
Key Features
- AMD B650 Chipset & AM5 Socket: Supports Ryzen 7000/8000 series desktop processors for next‑gen performance.
- DDR5 Memory Support: Dual‑channel up to 128 GB, overclockable to 6800+ MHz (1‑DIMM) / 6000+ MHz (2‑DIMM) with AMD EXPO.
- High‑Speed Networking: Integrated Realtek RTL8125BG 2.5 Gb Ethernet for fast wired connections.
- Expansion Slots: 1 PCI‑e x16 slot (up to x16), 1 PCI‑e x1 slot (PCIe 4.0 from CPU) and an additional PCIe 3.0 x1 slot.
- Storage Options: 1 M.2 slot (PCIe 4.0 x4) plus 4 SATA 6 Gb/s ports with RAID 0/1/10 support.
- Comprehensive USB Connectivity: 2 rear USB 2.0, 4 front USB 2.0, 4 rear USB 5 Gbps Type‑A, and 2 front USB 5 Gbps Type‑A ports.
- Onboard Graphics & Audio: HDMI 2.1 (4K 60 Hz) and VGA outputs; Realtek ALC897 7.1‑channel HD audio.
