Specifications
| Chipset | INTEL H470 |
| CPU | Supports 10th Gen Intel Core and Pentium Gold/Celeron processors for LGA 1200 Socket |
| Memory | 2x DDR4, Maximum Memory Capacity 64GB Memory Support 2933/ 2666/ 2400/ 2133 MHz Supports 1R 2133/ 2666/ 2933 MHz for Intel Core i9/ Core i7 CPU Supports 1R 2133/ 2666 MHz for Intel Core i5/ Core i3/ Pentium Gold and Celeron CPU Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel Extreme Memory Profile (XMP) |
| Onboard Graphics | 1x HDMI Support HDMI 1.4, maximum resolution of 4K 30Hz* 1x VGA Support VGA, maximum resolution of 2048×1536 50Hz, 1920×1200 60Hz *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| Slot | 1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 3.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) |
| Audio | Realtek ALC897 Codec 7.1-Channel High Definition Audio |
| Storage | 1x M.2 M.2_1 Source (From Chipset) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
| USB | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) |
| LAN | Realtek 8111H Gigabit LAN |
| Internal IO | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 4x USB 5Gbps Type A ports |
| LED FEATURE | 4x EZ Debug LED |
| BACK PANEL PORTS | HDMI VGA Keyboard / Mouse USB 5Gbps Type-A LAN port Audio Connectors USB 2.0 USB 2.0 |
| OPERATING SYSTEM | Support for Windows 11 64-bit, Windows 10 64-bit |
| PCB Info | mATX 202mmx236mm |
| Warranty | 3 Years |
Key Features
- Intel H470 Chipset – Supports 10th Gen Intel Core, Pentium Gold and Celeron CPUs on LGA 1200 socket.
- 64 GB DDR4 Memory – Dual‑channel, 2 × DIMM slots, up to 2933 MHz, XMP ready.
- Expansion Slots – 1 × PCI‑e 3.0 x16 slot for graphics and 1 × PCI‑e 3.0 x1 slot.
- Storage Flexibility – 1 × M.2 (PCIe 3.0 x4/SATA) plus 4 × SATA 6 Gb/s connectors.
- Comprehensive USB I/O – 4 × USB 2.0 rear, 4 × USB 2.0 front, 2 × USB 3.2 Gen 1 (5 Gbps) rear and front.
- Integrated Graphics Outputs – HDMI 1.4 (4K 30 Hz) and VGA (up to 2048×1536 50 Hz) for CPUs with iGPU.
- Networking & Audio – Realtek 8111H Gigabit LAN and Realtek ALC897 7.1‑channel HD audio.
- EZ Debug LEDs & TPM Support – 4‑color debug LEDs for troubleshooting and TPM 2.0 header for security.
- 3‑Year Warranty – Reliable MSI backing with three years of coverage.
