Specifications
| Platform | INTEL |
| Socket | LGA1851 |
| Cpu Type | Core Ultra |
| Chipset | Z890 |
| Memory Speed | up to 8800 |
| Max Memory Support | 256 GB |
| Supported Memory Type | DDR5 |
| Channel Supported | Dual Channel |
| Memory Feature | Supports Intel POR Speed and JEDEC Speed Supports Memory Overclocking and Intel® XMP 3.0 Supports Dual-Controller Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM |
| Graphics Port | 1 x HDMI,1 x DisplayPort,1 x Type-C DisplayPort |
| Expansion Slots | 4x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E4 Gen PCIe 4.0 supports up to x4 (From CPU) |
| Wireless Networking | WiFi 7,Bluetooth 5.4 |
| Back Panel I/O Ports | DisplayPort USB 5Gbps Type-A 2.5G LAN Wi-Fi / Bluetooth Audio Connectors HDMI™ Thunderbolt™ 4 40Gbps (Type-C) USB 20Gbps Type-C USB 5Gbps Type-A |
| Internal I/O Connector | 1x Thunderbolt5 card connector(JTBT5, support RTD3) 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 4x System Fan 1x EZ Conn-header (JAF_1) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 20Gbps Type C ports |
| Form Factor | ATX |
| Warranty | 3 Years |
| Note | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only. |
Key Features
- CPU Support: Intel Core Ultra processors, LGA1851 socket, Z890 chipset
- Memory: DDR5, up to 8800 MT/s, 256 GB max, dual‑channel, Intel XMP 3.0 & overclocking support
- Expansion Slots: 1× PCIe 5.0 x16 (CPU), 1× PCIe 4.0 x4 (chipset), 1× PCIe 4.0 x4 (CPU), 1× PCIe 3.0 x1 (chipset)
- Networking: Wi‑Fi 7, Bluetooth 5.4, 2.5 GbE LAN
- I/O Ports: Thunderbolt 4 (40 Gbps Type‑C), USB 20 Gbps Type‑C, USB 5 Gbps Type‑A, HDMI, DisplayPort, USB‑C DisplayPort
- Cooling & RGB: 1 CPU fan, 1 combo fan/pump, 4 system fan headers, 3× addressable V2 RGB, 1× RGB LED connectors
- Form Factor & Warranty: ATX, 3‑year limited warranty
