Specifications
| Marketing Name | GeForce RTX™ 5070 12G GAMING TRIO OC |
| Model Name | G5070-12GTC |
| Graphics Processing Unit | NVIDIA® GeForce RTX™ 5070 |
| Interface | PCI Express® Gen 5 |
| Core Clocks | Extreme Performance: 2625 MHz (MSI Center) | Boost: 2610 MHz |
| CUDA® Cores | 6144 Units |
| Memory Speed | 28 Gbps |
| Memory | 12GB GDDR7 |
| Memory Bus | 192-bit |
| Output Ports | 3x DisplayPort 2.1b | 1x HDMI 2.1b (Supports up to 4K 480Hz or 8K 120Hz with DSC, Gaming VRR, HDR) |
| HDCP Support | Yes |
| Power Consumption | 250W |
| Power Connectors | 1x 16-pin |
| Recommended PSU | 650W |
| Card Dimensions (mm) | 338 x 140 x 50 mm |
| Weight (Card / Package) | 1187g / 1705g |
| DirectX Version Support | 12 Ultimate |
| OpenGL Version Support | 4.6 |
| Maximum Displays | 4 |
| G-SYNC® Technology | Yes |
| Digital Maximum Resolution | 7680 x 4320 |
Key Features
- NVIDIA GeForce RTX™ 5070 GPU with 6144 CUDA cores
- 12GB GDDR7 memory at 28 Gbps on a 192‑bit bus
- Extreme performance clock up to 2625 MHz (Boost 2610 MHz) via MSI Center
- PCI Express® Gen 5 interface for maximum bandwidth
- Triple DisplayPort 2.1b + HDMI 2.1b outputs supporting up to 8K 120Hz or 4K 480Hz with DSC
- Power draw 250W, requires 1×16‑pin connector and a 650W PSU
- Supports G‑SYNC®, DirectX 12 Ultimate, OpenGL 4.6, and up to 4 simultaneous displays
- Compact triple‑fan design: 338 × 140 × 50 mm, weight 1187 g
