Specifications
| GPU | NVIDIA GeForce RTX 5060 |
| CUDA Cores | 3840 |
| Video Memory | 8GB GDDR7 |
| Memory Bus | 128-bit |
| Engine Clock | 2497 MHz |
| Memory Clock | 28 Gbps |
| PCI Express | PCI Express 5.0 x8 |
| Display Outputs | 3 × DisplayPort 2.1b (UHBR20), 1 × HDMI 2.1b |
| DisplayPort Support | Up to 4K @ 480Hz or 8K @ 165Hz with DSC |
| HDMI Support | Up to 4K @ 480Hz HDR or 8K @ 120Hz HDR with DSC, Gaming VRR |
| HDCP Support | 2.3 |
| Multi Display Capability | Quad Display |
| Recommended PSU | 550W |
| Power Consumption | 145W |
| Power Input | 1 × 8-pin |
| DirectX Support | Microsoft DirectX® 12 Ultimate |
| OpenGL Support | 4.6 |
| Cooling | Air Cooled |
| Slot Size | 2-slot |
| SLI Support | No |
| Supported OS | Windows 11 / 10 64-bit (v1809 or later) |
| Card Dimensions | 164.5 × 111.2 × 36.4 mm (6.5″ × 4.4″ × 1.4″) |
| Accessories | User Manual |
Key Features
- GPU: NVIDIA GeForce RTX 5060 with 3840 CUDA cores
- Memory: 8GB GDDR7, 28 Gbps memory clock
- Clock Speed: Engine clock up to 2497 MHz
- Interface: PCI Express 5.0 x8
- Display Outputs: 3× DisplayPort 2.1b (UHBR20) + 1× HDMI 2.1b – up to 4K @ 480Hz or 8K @ 165Hz (DP) / 4K @ 480Hz HDR or 8K @ 120Hz HDR (HDMI) with DSC
- Power: 145W TDP, single 8‑pin power connector, recommended 550W PSU
- Cooling & Size: Dual‑slot air‑cooled cooler, dimensions 164.5 × 111.2 × 36.4 mm
