Specifications
| CPU | Intelà Socket LGA1700 for 12th Gen Intelà Coreô, Pentiumà Gold and Celeronà Processors |
| Chipset | Intelà Z690 Chipset |
| Memory | 4 x DIMM, Max. 128GB, DDR5 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800 Non-ECC, Un-buffered Memory* |
| Graphics | 1 x DisplayPort** |
| Expansion Slots | Intelà 12th Gen Processors* |
| Storage | Supports 3 x M.2 slots and 6 x SATA 6Gb/s ports |
| Ethernet | 1 x Intelà 2.5Gb Ethernet |
| Wireless & Bluetooth | 2×2 Tri-Band Intel Wi-Fi a/b/g/n/ac/ax/az + BT5.2 |
| USB | Rear USB: Total 12 ports |
| Audio | “ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 |
| Intrernal I/O Connectors | Fan and Cooling related |
| Special Features | Extreme Engine Digi+ |
| Software Features | ROG Exclusive Software |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Manageability | WOL by PME, PXE |
| Accessories | Cables |
| Operating System | Windowsà 11 64-bit, Windowsà 10 64-bit |
| Form Factor | ATX |
| Warranty | 3 Years |
Key Features
- CPU Socket: Intel LGA1700 for 12th Gen Core, Pentium Gold and Celeron processors
- Chipset: Intel Z690
- Memory: 4 DIMM slots, up to 128GB DDR5, speeds up to 6400(OC) MT/s
- Storage: 3 x M.2 slots + 6 x SATA 6Gb/s ports
- Networking: 2.5Gb Ethernet + Tri-Band Intel Wi-Fi 6E (ax/az) + Bluetooth 5.2
- USB: 12 rear USB ports
- Audio: ROG SupremeFX 7.1 Surround Sound with ALC4080 codec
- Warranty & Build: ATX form factor, 3-year warranty, UEFI AMI BIOS with 256Mb Flash ROM
