CPU: AMD Socket AM5, supports Ryzen 7000/8000/9000 series processors.
Chipset: AMD B650.
Memory: DDR5 up to 6400(OC) MT/s, 2 DIMM slots, max 128 GB (64 GB per DIMM), dual‑channel, non‑ECC unbuffered, supports EXPO/XMP.
Onboard Graphics: Integrated AMD Radeon graphics with D‑Sub (1920×1200@60Hz) and HDMI (4096×2160@60Hz, HDMI 2.1, HDCP 2.3).
Audio: Realtek HD Audio codec, 2/4/5.1/7.1‑channel.
LAN: Realtek 2.5GbE (2.5/1/0.1 Gbps).
Wireless: AzureWave Wi‑Fi AW‑CB304NF (RTL8821CE), 802.11a/b/g/n/ac dual‑band, Bluetooth 4.2.
Expansion Slots: 1× PCIe x16 (CPU‑linked, PCIe 4.0 x8/x4 depending on CPU) + 1× PCIe x1 (chipset, PCIe 3.0).
Storage: 1× M.2 Socket 3 M.2 2280 (PCIe 4.0 x4/x2) + 4× SATA 6Gb/s, RAID 0/1/10 support.
USB: Rear: 2× USB 3.2 Gen 1, 1× USB 2.0; Internal: 2× USB 3.2 Gen 1 header, 5× USB 2.0 (3 rear, 2 header) plus 2× USB 2.0 via hub.
