Specifications
| Marketing Name | GeForce RTX™ 5060 8G GAMING TRIO OC WHITE |
| Model Name | G5060-8GTCW |
| GPU | NVIDIA® GeForce RTX™ 5060 |
| Interface | PCI Express® Gen 5 x16 (uses x8) |
| Core Clocks | Extreme: 2640 MHz (via MSI Center), Boost: 2625 MHz |
| CUDA® Cores | 3840 |
| Memory Speed | 28 Gbps |
| Memory | 8GB GDDR7 |
| Memory Bus | 128-bit |
| Output Ports | 3 × DisplayPort 2.1b, 1 × HDMI 2.1b |
| HDCP Support | Yes |
| Power Consumption | 155 W |
| Power Connectors | 1 × 8-pin |
| Recommended PSU | 550 W |
| Card Dimensions | 300 × 125 × 44 mm |
| Weight (Card / Package) | 797 g / 1206 g |
| DirectX Support | 12 Ultimate |
| OpenGL Support | 4.6 |
| Maximum Displays | 4 |
| G-SYNC® Technology | Yes |
| Digital Max Resolution | 7680 × 4320 (8K) |
Key Features
- NVIDIA GeForce RTX 5060 GPU with 3840 CUDA cores
- Boost clock up to 2625 MHz (Extreme 2640 MHz via MSI Center)
- 8GB GDDR7 memory at 28 Gbps on a 128‑bit bus
- 3× DisplayPort 2.1b + 1× HDMI 2.1b, supporting up to 8K (7680×4320) resolution
- PCI Express Gen 5 x16 interface (operates at x8)
- G‑SYNC compatible, DirectX 12 Ultimate, OpenGL 4.6 support
- 155 W power draw with a single 8‑pin connector, recommended 550 W PSU
- Compact triple‑fan design: 300 mm × 125 mm × 44 mm, 797 g weight
