Specifications
| Marketing Name | GeForce RTX™ 5060 Ti 16G VENTUS 2X PLUS |
| Model Name | G506T-16V2P |
| Graphics Processing Unit | NVIDIA® GeForce RTX™ 5060 Ti |
| Interface | PCI Express® Gen 5 x16 (uses x8) |
| Core Clocks | Extreme Performance: 2587 MHz (MSI Center)Boost: 2572 MHz |
| Cores | 4608 Units |
| Memory Speed | 28 Gbps |
| Memory | 16GB GDDR7 |
| Memory Bus | 128-bit |
| Output | 3x DisplayPort (v2.1b)1x HDMI™ (2.1b: up to 4K 480Hz or 8K 120Hz with DSC, Gaming VRR, HDR) |
| HDCP Support | Yes |
| Power Consumption | 180W |
| Power Connectors | 1x 8-pin |
| Recommended PSU | 600W |
| Card Dimension (mm) | 227 x 127 x 41 mm |
| Weight (Card / Package) | 600 g / 862 g |
| OpenGL Version Support | 4.6 |
| Maximum Displays | 4 |
| G-SYNC™ Technology | Yes |
| Digital Maximum Resolution | 7680 x 4320 |
| UPC | 0824142419342 |
Key Features
- Powered by the NVIDIA® GeForce RTX™ 5060 Ti with 4608 CUDA cores.
- Equipped with 16GB GDDR7 memory running at 28 Gbps for high bandwidth.
- Features a Boost Clock of up to 2572 MHz for extreme performance.
- Includes 3x DisplayPort 2.1b and 1x HDMI 2.1b, supporting up to 4K 480Hz or 8K 120Hz with DSC.
- Supports G-SYNC™ technology for tear-free gaming.
- Requires 180W power consumption with a single 8-pin connector and a recommended 600W PSU.
- Compact form factor measuring 227 x 127 x 41 mm.
