Specifications
| Marketing Name | GeForce RTX™ 5060 8G VENTUS 3X OC |
| Model Name | G5060-8V3C |
| Graphics Processing Unit | NVIDIA® GeForce RTX™ 5060 |
| Interface | PCI Express® Gen 5 x16 (uses x8) |
| Core Clocks | Extreme: 2550 MHz (via MSI Center), Boost: 2535 MHz |
| CUDA® Cores | 3840 |
| Memory Speed | 28 Gbps |
| Memory | 8GB GDDR7 |
| Memory Bus | 128-bit |
| Output | 3 × DisplayPort 2.1b, 1 × HDMI 2.1b |
| HDCP Support | Yes |
| Power Consumption | 145 W |
| Power Connectors | 1 × 8-pin |
| Recommended PSU | 550 W |
| Card Dimensions | 303 × 121 × 41 mm |
| Weight (Card / Package) | 684 g / 1042 g |
| DirectX Version Support | 12 Ultimate |
| OpenGL Version Support | 4.6 |
| Maximum Displays | 4 |
| G-SYNC® Technology | Yes |
| Digital Maximum Resolution | 7680 × 4320 |
Key Features
- GPU: NVIDIA GeForce RTX 5060
- CUDA Cores: 3840
- Clock Speeds: Boost up to 2535 MHz (Extreme 2550 MHz via MSI Center)
- Memory: 8 GB GDDR7, 28 Gbps, 128‑bit bus
- Power: 145 W TDP, 1×8‑pin connector, 550 W PSU recommended
- Outputs: 3× DisplayPort 2.1b, 1× HDMI 2.1b (up to 4 displays, 7680×4320)
- Features: DirectX 12 Ultimate, OpenGL 4.6, G‑SYNC support
