Specifications
| Marketing Name | GeForce RTX™ 5070 12G INSPIRE 3X OC |
| Model Name | G5070-12I3C |
| Graphics Processing Unit | NVIDIA® GeForce RTX™ 5070 |
| Interface | PCI Express® Gen 5 |
| Core Clocks | Extreme Performance: 2557 MHz (MSI Center) | Boost: 2542 MHz |
| CUDA® Cores | 6144 Units |
| Memory Speed | 28 Gbps |
| Memory | 12GB GDDR7 |
| Memory Bus | 192-bit |
| Output Ports | 3x DisplayPort 2.1b | 1x HDMI 2.1b (Supports up to 4K 480Hz or 8K 120Hz with DSC, Gaming VRR, HDR) |
| HDCP Support | Yes |
| Power Consumption | 250W |
| Power Connectors | 1x 16-pin |
| Recommended PSU | 650W |
| Card Dimensions (mm) | 288 x 112 x 50 mm |
| Weight (Card / Package) | 914g / 1312g |
| DirectX Version Support | 12 Ultimate |
| OpenGL Version Support | 4.6 |
| Maximum Displays | 4 |
| G-SYNC® Technology | Yes |
| Digital Maximum Resolution | 7680 x 4320 |
Key Features
- GPU: NVIDIA GeForce RTX 5070 with 6144 CUDA cores for high‑performance ray tracing and AI workloads.
- Clock Speeds: Extreme Performance boost up to 2557 MHz (Boost 2542 MHz) via MSI Center.
- Memory: 12 GB GDDR7 running at 28 Gbps on a 192‑bit bus, delivering fast data throughput.
- Interface: PCI Express Gen 5 for maximum bandwidth and future‑proof connectivity.
- Display Outputs: 3× DisplayPort 2.1b and 1× HDMI 2.1b supporting up to 8K 120 Hz (with DSC) or 4K 480 Hz, VRR, HDR and HDCP.
- Power: 250 W TDP, powered by a single 16‑pin connector; recommended 650 W PSU.
- Form Factor: Compact design measuring 288 mm × 112 mm × 50 mm, weighing 914 g, with support for DirectX 12 Ultimate, G‑SYNC and up to 4 displays at 7680 × 4320 resolution.
