Specifications
| Marketing Name | GeForce RTX™ 5080 16G VENTUS 3X OC PLUS |
| Model Name | G5080-16V3CP |
| Graphics Processing Unit | NVIDIA® GeForce RTX™ 5080 |
| Interface | PCI Express® Gen 5 |
| Core Clocks | Extreme Performance: 2655 MHz (MSI Center) |
| Boost Clock | 2640 MHz |
| CUDA® Cores | 10752 Units |
| Memory Speed | 30 Gbps |
| Memory Size | 16GB GDDR7 |
| Memory Bus | 256-bit |
| Output Ports | 3x DisplayPort 2.1b, 1x HDMI™ 2.1b |
| HDCP Support | Yes |
| Power Consumption | 360W |
| Power Connectors | 16-pin x 1 |
| Recommended PSU | 850W |
| Card Dimensions (mm) | 303 x 121 x 49 mm |
| Weight (Card / Package) | 1105 g / 1618 g |
| DirectX Version | 12 Ultimate |
| OpenGL Version | 4.6 |
| Maximum Displays | 4 |
| G-SYNC® Technology | Yes |
| Digital Max Resolution | 7680 x 4320 |
Key Features
- NVIDIA GeForce RTX 5080 GPU with 10,752 CUDA cores for high-performance ray tracing and AI workloads.
- Extreme Performance clock of 2,655 MHz (MSI Center) and Boost clock up to 2,640 MHz.
- 16GB GDDR7 memory running at 30 Gbps on a 256‑bit bus for fast texture and frame buffering.
- PCI Express Gen 5 interface ensures maximum bandwidth and future‑proof connectivity.
- Triple DisplayPort 2.1b and HDMI 2.1b outputs support up to 4 simultaneous displays and 7680×4320 resolution.
- G‑SYNC technology provides smooth, tear‑free gaming with variable refresh rates.
- 360W power draw with a single 16‑pin connector; recommended 850W PSU for stable operation.
