Specifications
| SKU | 11349-03-20G |
| GPU Model | SAPPHIRE PULSE AMD Radeon™ RX 9070 |
| Architecture | AMD RDNA™ 4 |
| Engine Clock | Boost Clock: Up to 2520 MHzGame Clock: Up to 2070 MHz |
| Stream Processors | 3584 |
| Compute Units | 56 CUs (3rd Gen RT + 2nd Gen AI Accelerators) |
| Infinity Cache | 64MB |
| Ray Accelerators | 56 |
| AI Accelerators | 112 |
| Memory Size & Bus | 16GB GDDR6 / 256-bit |
| Memory Clock | 20 Gbps Effective |
| Max Displays | 4 |
| Max Resolution | HDMI®: 7680×4320DisplayPort™ 2.1a: 7680×4320 |
| Interface | PCI-Express 5.0 x16 |
| Outputs | 2x HDMI®2x DisplayPort™ 2.1a |
| BIOS Support | UEFI |
| Game Index | 4K |
| Power Consumption | 220W Typical Board Power |
| Minimum PSU Requirement | 650W |
| Power Connector | 2 x 8-pin |
| Form Factor | 2.5 slot, ATX |
| Dimensions | 280mm (L) x 120.25mm (W) x 51.5mm (H) |
| Cooling System | Dual-X Cooling Technology |
| Fan Type | Two-Ball Bearing Fans |
| Sapphire Features | Honeywell PTM7950 TIM, AeroCurve Fan Blade, Free Flow, FrameDefense, Integrated Cooling Module, High TG Copper PCB, Optimized Composite Heatpipes, Metal Backplate, 12-Phase Digital Power Design, Fuse Protection, Intelligent Fan Control, Precision Fan Control |
| Software & Technologies | AMD HYPR-RX with AFMF 2, AMD FidelityFX™ Super Resolution 4 with AI Upscaling, AMD Fluid Motion Frames 2, AMD Radeon™ Anti-Lag 2, AMD Noise Suppression, AMD Freesync™, AMD Smart Technologies, Microsoft® DirectX® 12 Ultimate, AMD Software: Adrenalin Edition™ |
| Operating Systems | Linux®, Windows® 10 & 11 (64-bit required) |
| Warranty | 3 Years |
Key Features
- GPU Architecture: AMD RDNA™ 4
- Clock Speeds: Boost Clock up to 2520 MHz (Game Clock up to 2070 MHz)
- Memory: 16GB GDDR6, 256-bit bus, 20 Gbps effective
- Processing Power: 3584 Stream Processors, 56 Compute Units, 56 Ray Accelerators, 112 AI Accelerators
- Cooling: Dual-X Cooling Technology with Two-Ball Bearing Fans, Honeywell PTM7950 TIM, AeroCurve Fan Blade
- Display Outputs: 2x HDMI, 2x DisplayPort 2.1a; supports up to 4 monitors, 8K (7680×4320) resolution
- Interface & Power: PCI‑Express 5.0 x16, 220W typical board power, requires 650W PSU, 2×8‑pin power connectors
- Warranty: 3‑year limited warranty
